K2-SRC P K H
a 0,6 - 3,2 mm pmax g g p f
d
d-0,05
d 1
d
M d
D D D
0,07 - 0,14 h m
| ISO | D | L | d | d1 | l1 | H | M | 1 2 3 4 5 6 7 8 | max. | kg | |||||
| 08K2R025A10-SRC08-A | 8 | 110 | 10 | 7,5 | 25 | – | – | 2 | – | 56000 | – | 0,08 | GI030 | CO530 | |
| 08K2R050A12-SRC08-A | 8 | 140 | 12 | – | 13,5 | – | – | 2 | – | 56000 | – | 0,11 | GI030 | CO530 | |
| 10K2R030A12-SRC10-A | 10 | 130 | 12 | 9,0 | 30 | – | – | 2 | – | 42000 | – | 0,11 | GI031 | CO531 | |
| 10K2R060A16-SRC10-A | 10 | 150 | 16 | – | 19,5 | – | – | 2 | – | 42000 | – | 0,18 | GI031 | CO531 | |
| 12K2R030A12-SRC12-A | 12 | 130 | 12 | 10,5 | 30 | – | – | 2 | – | 35000 | – | 0,11 | GI032 | CO532 | |
| 16K2R035A16-SRC16-A | 16 | 140 | 16 | 14,0 | 35 | – | – | 2 | – | 22000 | – | 0,23 | GI033 | CO533 | |
| DIN 1835A | 20K2R045A20-SRC20-A | 20 | 160 | 20 | 18,0 | 45 | – | – | 2 | – | 16000 | – | 0,40 | GI034 | CO534 |
| 25K2R045A25-SRC25-A | 25 | 160 | 25 | 22,4 | 45 | – | – | 2 | – | 10000 | – | 0,59 | GI035 | CO535 | |
| 32K2R060A32-SRC32-A | 32 | 180 | 32 | 28,6 | 60 | – | – | 2 | – | 6000 | – | 1,10 | GI036 | CO536 | |
| 12K2R060A16-SRC12-A | 12 | 160 | 16 | – | 24,5 | – | – | 2 | – | 35000 | – | 0,14 | GI032 | CO532 | |
| 16K2R065A20-SRC16-A | 16 | 175 | 20 | – | 31,5 | – | – | 2 | – | 22000 | – | 0,41 | GI033 | CO533 | |
| 20K2R080A25-SRC20-A | 20 | 190 | 25 | – | 33,5 | – | – | 2 | – | 16000 | – | 0,66 | GI034 | CO534 | |
| 08K2R30M06-SRC08-A | 8 | 45 | 6,5 | – | – | 30 | M6 | 2 | – | – | – | 0,02 | GI123 | CO530 | |
| 10K2R30M06-SRC10-A | 10 | 45 | 6,5 | – | – | 30 | M6 | 2 | – | – | – | 0,03 | GI124 | CO531 | |
| 12K2R30M06-SRC12-A | 12 | 45 | 6,5 | – | – | 30 | M6 | 2 | – | – | – | 0,16 | GI125 | CO530 | |
| MODULAR | 12K2R30M08-SRC12-A | 12 | 48 | 8,5 | – | – | 30 | M8 | 2 | – | – | – | 0,04 | GI125 | CO532 |
| 16K2R35M08-SRC16-A | 16 | 53 | 8,5 | – | – | 35 | M8 | 2 | – | – | – | 0,05 | GI033 | CO533 | |
| 20K2R35M10-SRC20-A | 20 | 54 | 10,5 | – | – | 35 | M10 | 2 | – | – | – | 0,08 | GI034 | CO534 |
| GI030 | RC 08 | RC 08-F | LC 08-KP | LC 08-KPF | – | – |
| GI031 | RC 10 | RC 10-F | LC 10-KP | LC 10-KPF | – | – |
| GI032 | RC 12 | RC 12-F | – | – | LC 12..-CH | LC 12..-RE |
| GI033 | RC 16 | RC 16-F | – | – | – | – |
| GI034 | RC 20 | RC 20-F | – | – | – | – |
| GI035 | RC 25 | RC 25-F | – | – | – | – |
| GI036 | RC 32 | RC 32-F | – | – | – | – |
| GI123 | RC 08 | RC 08-F | – | – | – | – |
| GI124 | RC 10 | RC 10-F | – | – | – | – |
| GI125 | RC 12 | RC 12-F | – | – | – | – |
