Tooling by DIJET Indexable Tools Mirror Radius RnMTyPE Radius form accuracy ■ INSERTS of insert: within ±0.010mm ● RNM-□□□-R0 Diamond Dimensions (mm) PVD coated coated Uncoated Cat. No. JC8015 DH103 JC10000 KT9 r S A B T (Z10~20) (Z05) (K10) RNM-060-R03 ● ● 0.3 RNM-060-R05 ● ● 0.5 2 6 5 2 RNM-060-R10 ● ● 1 RNM-080-R03 ● ● □ 0.3 RNM-080-R05 ● ● ● ● 0.5 2.7 8 7 2.4 RNM-080-R10 ● ● □ ● 1 RNM-100-R0 ● ※ RNM-100-R03 ● ● □ 0.3 RNM-100-R05 ● ● ● ● 0.5 ● ● □ ● 3.3 10 8.5 2.6 RNM-100-R10 1 RNM-100-R15 □ □ 1.5 RNM-100-R20 ● ● ● 2 RNM-120-R0 ● ※ RNM-120-R03 ● ● □ 0.3 RNM-120-R05 ● ● □ ● 0.5 ● ● □ ● 4 12 10 3 RNM-120-R10 1 RNM-120-R15 ● ● ● 1.5 RNM-120-R20 ● ● ● 2 RNM-160-R0 ● ※ RNM-160-R03 ● ● ● 0.3 RNM-160-R05 ● ● ● 0.5 ● ● ● 5.3 16 12 4 RNM-160-R10 1 RNM-160-R15 ● ● □ 1.5 RNM-160-R20 ● ● ● 2 RNM-200-R0 ● ※ RNM-200-R03 ● ● ● 0.3 ● ● ● 6.7 20 15 5 RNM-200-R05 0.5 RNM-200-R10 ● ● ● 1 2 inserts per case, but grade JC10000 insert is packed in 1 piece per case. ※ Corner radius: Below 0.1mm Note) Please refer page C204 for “Instructions for mounting insert.” C196 : Standard stock items □ : Stock in Japan ◎ : Soon to be stocked ○ : Soon to be deleted
