Tooling by DIJET Indexable Tools QM MAX QXPTyPE Through Coolant Hole ● For High Feed Milling ● For Shoulder Milling φDb φDb φd φd a a b b ℓ ℓ Lf Lf 1.0 φd1 R1.2 φd1 R0.4~R2.0 φDc φDc ● For High Feed Milling ● For Shoulder Milling (QXP-8066R) φDb (QXP-8066R) φDb φd φd a a b b ℓ ℓ Lf Lf 1.0 φd1 R1.2 φd1 R0.4~R2.0 φDc φDc ■ BODY / FACE MILL TYPE Dimensions (mm) No. Type Cat. No. Stock of Inserts flutes φDc Lf φDb φd φd1 a b ℓ QXP-6040R-16 ● 6 40 45 35 16 14 8.4 5.6 18 QXP-7040R-16 ● 7 40 45 35 16 14 8.4 5.6 18 EP**1003**Z*R QXP-7050R-22 ● 7 50 50 40 22 17 10.4 6.3 20 Metric Bore QXP-8050R-22 ● 8 50 50 40 22 17 10.4 6.3 20 ZPMT1003**ZER QXP-8052R-22 ● 8 52 50 40 22 17 10.4 6.3 20 YPHW1003**ZER-** QXP-8063R-22 ● 8 63 50 48 22 17 10.4 6.3 20 QXP-8066R-27 ● 8 66 50 48 27 20 12.4 7 22 Note) 1. All cutters are supplied without inserts. Modular Head Type Please refer Page B030 2. Please refer page C038-C069 for recommended cutting conditions. ■ PARTS Clamp Screw Wrench DSW-2563H A-08 Recommended Torque Clamp Screw N・m DSW-2563H 0.9 C056 : Standard stock items □ : Stock in Japan ○ : Soon to be deleted
