Tooling by DIJET
Indexable Tools
SKS G II SKGTyPE

■ FACE MILL TYPE (Insert 14-type)
Fig.1 Through Coolant Hole


■ BODY
Dimensions (mm) Applicable
inserts
Type


Weight Fig.
Cat. No. No. Set Bolt
φDc Lf φDb φd φd1 a
Stock
of
inserts
b ℓ (kg)
SPNW
140515ZTR
SKG-4050R-14-22 4 50 50 40 22 9.6 10.4 6.3 19.05 M10x1.5x35* Head cap 0.3 1 Parts
screw Clamp screw
SKG-4052R-14-22 4 52 50 42 22 17 10.4 6.3 19.05 M10x1.5x35* (Slim Head) 0.3 1
4 63 50 48 22 17 10.4 6.3 20 0.5 1
Metric Bore


SKG-4063R-14-22 M10
Head cap screw
(JIS Standard)
SKG-4063R-14-27 4 63 50 48 27 20 12.4 7 22 M12x1.75x35* 0.5 1 CSW-513H
Wrench
SKG-5066R-14-27 5 66 50 50 27 20 12.4 7 22 M12x1.75x35* 0.5 1
SKG-5080R-14-27 5 80 50 60 27 37 12.4 7 22 M12x1.75x35* 0.8 1
SKG-6100R-14-32 6 100 63 70 32 45 14.4 8 25 M16 1.6 1 A-20
Note) 1. All cutters are supplied without inserts. Clamp Screw Recommended Torque
(N·m)
2. mark shows: these cutter bodies are equipped with the set bolt because of
*
the specified bolt size. CSW-513H 5.5
Except for these cutter bodies, please use the set bolt equipped with arbor.
3. Set bolt (M10×1.5×35) is slim head type with Ø13 head dia.

■ Insert 14-type


PVD coated
Cat. No. Tolerance
JC8050 JC8118
SPNW140515ZTR N ● ●
10 inserts per case.

C016 : Standard stock items □ : Stock in Japan ○ : Soon to be deleted
