- NORMY DOTYCZkCE PODSTAWOWYCH UCHWYTÓW
- MALAFA STANDARTLARI
DIN 69871 A-B
| IS | O | 30 | 40 | 45 | 50 | 60 |
| a | ± 0.01 | 3.2 | ||||
| b | H12 | 1 | 6.1 | 19.3 | 25 | .7 |
| d1 | 31.75 | 44.45 | 57.15 | 69.85 | 107,95 | |
| d2 | M12 | M16 | M20 | M24 | M30 | |
| d3 | H7 | 13 | 17 | 21 | 25 | 32 |
| d5 | ± 0.05 | 59.3 | 72.3 | 91.35 | 107.25 | 164,75 |
| d6 | 0 -0.1 | 50 | 63.55 | 82.55 | 97.50 | 155 |
| d7 | 0 -0.5 | 44.3 | 56.25 | 75.25 | 91.25 | 147,70 |
| d8 | max. | 45 | 50 | 63 | 80 | 130 |
| d9 | 4 | 5 | 6 | 8 | ||
| e1 | ± 0.1 | 21 | 27 | 35 | 42 | 66 |
| e2 | max. | 5 | 6 | 7 | 9,2 | |
| f1 | ± 0.1 | 11.1 | ||||
| f2 | min. | 3 | 5 | 38 | ||
| f3 | 0 -0.1 | 19.1 | ||||
| l1 | 0 -0.3 | 47.8 | 68.4 | 82.7 | 101.75 | 161,80 |
| l2 | +0.5 0 | 5.5 | 8.2 | 10 | 11.5 | 14 |
| l3 | min. | 24 | 32 | 40 | 47 | 59 |
| l5 | 0 -0.3 | 15 | 18.5 | 24 | 30 | 49 |
| l6 | 0 -0.4 | 16.4 | 22.8 | 29.1 | 35.5 | 54,5 |
| l7 | 0 -0.4 | 19 | 25 | 31.3 | 37.7 | 59,3 |
MAS 403 BT A-B
249
| IS | O | 30 | 35 | 40 | 45 | 50 | 60 |
| a | ± 0.04 | 2 | 3 | ||||
| b | H12 | 16.1 | 19.3 | 25.7 | 25,7 | ||
| d1 | 31.75 | 38.10 | 44.45 | 57.15 | 69.85 | 107,95 | |
| d2 | M | 12 | M 16 | M 20 | M 24 | M30 | |
| d3 | H8 | 12 | .5 | 17 | 21 | 25 | 31 |
| d4 | 38 | 43 | 53 | 73 | 85 | 135 | |
| d5 | h8 | 46 | 53 | 63 | 85 | 100 | 155 |
| d6 | 56.144 | 65.680 | 75.679 | 100.215 | 119.019 | 180,359 | |
| d7 | 8 | 1 | 0 | 12 | 15 | 20 | |
| d8 | 4 | 5 | 6 | 8 | |||
| e1 | ± 0.1 | 21 | 23 | 27 | 35 | 42 | 66 |
| e2 | max. | 5 | 6 | 7 | 9,2 | ||
| f1 | ± 0.1 | 13.6 | 14.6 | 16.6 | 21.2 | 23.2 | 28,2 |
| f2 | 22 | 24 | 27 | 33 | 38 | 4,8 | |
| f3 | min. | 17 | 20 | 21 | 26 | 31 | 34 |
| f4 | 4 | 5 | 6 | 7 | 11 | ||
| f5 | +0.1 0 | 8 | 1 | 0 | 12 | 15 | 20 |
| l1 | ± 0.2 | 48.4 | 56.4 | 65.4 | 82.8 | 101.8 | 161,8 |
| l2 | +0.5 0 | 7 | 9 | 11 | 13 | 16 | |
| l3 | min. | 2 | 4 | 30 | 38 | 45 | 56 |
| l4 | 0 -0.2 | 16.3 | 19.6 | 22.6 | 29.1 | 35.4 | 60,1 |
