Общий каталог D'ANDREA 2018 - страница 179

• HIGH PRECISION ULTRA-TIGHT TOOLHOLDER • ВЫСОКОЖЕСТКИЕ СВЕРХТОЧНЫЕ ДЕРЖАТЕЛИ MONOforce • OPRAWKA PRECYZYJNA O DU¾EJ SILE ZACISKU • VYSOCE P¢ESN¹ A VELMI PEVN¹ NÁSTROJOV¹ DR½ÁK • YÜKSEK HASSASIYETLI ULTRA SIKI TAKIM TUTUCU DIN 69893 HSK-A 178 fig.1 • Supplied with coolant tube - without clamping wrench • В комплект входит соединительная втулка для СОЖ, зажимный ключ не входит в комплект поставки fig.2 •:\SRVDƅRQDZ]ŕĝF]NĸGRFLHF]\FKŕRG]ĝFHMtNOXF]]DFLVNRZ\QLHMHVWQDZ\SRVDƅHQLX • 'RG¾YDQÚVFKODGLFÊPSRWUXEÊPEH]XSÊQDFÊKRNOÊĦH •6RĽXWPDVIJYIJVIJERUXVX\ODVIJNIJūWIJUPDDQDKWDUIJROPDGDQWHGDULNHGLOLU HSK-A REF. CODE d1 d2 d3 H L L1 L2 kg fig. HSK-A63 MF12.70 71HSK-A63MF1207 12 28 – 46 70 44 – 0.8 1 HSK-A63 MF12.100 71HSK-A63MF1210 32 100 74 29.5 1.1 2 63 HSK-A63 MF20.85 71HSK-A63MF2008 20 48 60 85 59 1.2 1 HSK-A63 MF20.125 71HSK-A63MF2012 125 99 – 1.7 2 HSK-A63 MF32.105 71HSK-A63MF3210 – 105 – 2 1 HSK-A63 MF32.140 71HSK-A63MF3214 32 66 80 140 2.6 2 100 HSK-A100 MF32.110 71HSKA100MF3211 110 81 – 3.1 1 HSK-A100 MF32.160 71HSKA100MF3216 160 131 3.6 KIT K01 K01 MONOforce 12 K01 MONOforce 20 KIT K01 MONOforce 32 HSK-A63 1 MONOforce 12 1 MONOforce 20 1 MONOforce 32 1 RC 12.04 1 RC 20.06 1 RC 32.06 1 RC 12.06 1 RC 20.08 1 RC 32.08 1 RC 12.08 1 RC 20.10 1 RC 32.10 1 RC 12.10 1 RC 20.12 1 RC 32.12 1 CHV 28 1 RC 20.16 1 RC 32.16 1 CHV 50 1 RC 32.20 1 RC 32.25 1 CHV 75 HSK-A REF. CODE KIT K01 MONOFORCE 12.70 HSK63 7KHSK-A63MF1207 63 KIT K01 MONOFORCE 20.85 HSK63 7KHSK-A63MF2008 KIT K01 MONOFORCE 32.105 HSK63 7KHSK-A63MF3210 KIT K01 K01 MONOforce 20 KIT K01 MONOforce 32 HSK-A100 1 MONOforce 20 1 MONOforce 32 1 RC 20.06 1 RC 32.06 1 RC 20.08 1 RC 32.08 1 RC 20.10 1 RC 32.10 1 RC 20.12 1 RC 32.12 1 RC 20.16 1 RC 32.16 1 CHV 50 1 RC 32.20 1 RC 32.25 1 CHV 75 HSK-A REF. CODE 100 KIT K01 MONOFORCE 32.110 HSK100 7KHSKA100MF3211 248 241 240 222 222 222
