D dA TiAlN l PM-HSS NC-Anbohrer SP Powder metal NC spot drills Foret à pointer-PM-HSS NC NC - Anbohrer 90° / NC spot drill 90° / Foret à pointer NC 90° 2 Schneiden, 90° / 2 flutes, 90° / 2 dents, 90° h6 450 – 488 90° h6 2,0 -20,0 mm 2 l2 PM-HSS ✓ PG 24 beschichtet coated revêtu Schaft Shank D dA l l2 Tige h6 h6 SPA0020-090-PM 2 2 40 8  SPA0030-090-PM 3 3 40 10  SPA0040-090-PM 4 4 40 12  SPA0050-090-PM 5 5 50 15  SPA0060-090-PM 6 6 50 20  SPA0080-090-PM 8 8 63 22  SPA0100-090-PM 10 10 74 23  SPA0120-090-PM 12 12 83 25  SPA0140-090-PM 14 14 83 26  SPA0160-090-PM 16 16 92 28  SPA0180-090-PM 18 18 92 30  SPA0200-090-PM 20 20 104 30      Hauptanwendung Main application Application principale  Nebenanwendung Secondary application Application secondaire 444 VHM- / PM-HSS Werkzeuge | Solid carbide- / PM-HSS Tools | Outils carbure monobloc / PM-HSS Alle Angaben in mm / Dimensions in mm SP
