d d3 dA TiAlN FP l PM-HSS-Schruppfräser FP PM-HSS roughing end-mill Fraise d‘ébauche-PM-HSS FP623.1-… 4-5 Schneiden, extra lange Ausführung / 4-5 flutes, extra long design / 4 - 5 dents, version extra longue HB 346 – 350 30° 4-5 PM-HSS ✓ l1 l2 PG 24 beschichtet coated revêtu Schaft DIN 6535HB Shank d dA d3 l1 l2 l z Tige js12 h6 FP62341-100 10 10 8,5 22 69 110 4  FP62341-120 12 12 10,5 26 78 125 4  FP62341-160 16 16 14,0 32 87 138 4  FP62341-200 20 20 18,0 38 108 160 4  FP62351-250 25 25 23,0 45 155 216 5       Hauptanwendung Main application Application principale  Nebenanwendung Secondary application Application secondaire Alle Angaben in mm / Dimensions in mm / Toutes les dimensions en mm VHM- / PM-HSS Werkzeuge | Solid carbide- / PM-HSS Tools | Outils carbure monobloc / PM-HSS 345
