TN6025201851720185222018528311823431182363118240311823831182423118374311837631183783118380312201531220183122017 Threading Laydown Threading Threading Inserts (ER/L-ISO — continued) P ⅷ M ⅷ ⅷ first choice K ⅷ ࠗ alternate choice N ࠗ S ⅷ ISO Metric- External H insert thread catalogue number EX E size pitch mm TPI TPF 4ER50ISO 1,7 2,5 4 5,00 — — 5ER55ISO 2,7 1,9 5 5,50 — — 5ER60ISO 2,9 2,0 5 6,00 — — left hand 2EL05ISO 0,6 0,4 2 0,50 — — 2EL06ISO 0,6 0,6 2 0,60 — — 2EL07ISO 0,6 0,6 2 0,70 — — 2EL075ISO 0,6 0,6 2 0,75 — — 2EL08ISO 0,6 0,6 2 0,80 — — 2EL10ISO 0,7 0,7 2 1,00 — — 2EL125ISO 0,8 0,9 2 1,25 — — 2EL15ISO 0,8 1,0 2 1,50 — — 2EL175ISO 0,8 1,1 2 1,75 — — 3EL035ISO 0,8 0,4 3 0,35 — — 3EL04ISO 0,7 0,4 3 0,40 — — 3EL045ISO 0,7 0,4 3 0,45 — — widia.com F49
