Grooving and Cut-Off TN60103606967360697136071823606968360697236069693606973–3606974 TN6025––––––––– TN7110––––––––– THM36070373607041–360703836070423607039360704336070403607044 TopGroove™ Grooving Inserts (NGP • Grooving Positive Rake Inserts — continued) P ⅷ ⅷ ⅷ M ⅷ ⅷ ࠗ ⅷ first choice K ⅷ ࠗ ࠗ ࠗ ࠗ alternate choice N ⅷ ࠗ ⅷ S ⅷ ⅷ ⅷ H ࠗ ࠗ Right-hand insert shown; left-hand insert is mirror image. insert catalogue number size W RR T left hand NGP2M150L 2 1,50 0,19 2,79 NGP3M150L 3 1,50 0,19 1,90 NGP2062L 2 1,57 0,19 2,79 NGP2M200L 2 2,00 0,19 2,79 NGP3M200L 3 2,00 0,19 2,79 NGP2M250L 2 2,50 0,19 2,79 NGP3M250L 3 2,50 0,19 3,81 NGP2M300L 2 3,00 0,19 2,79 NGP3M300L 3 3,00 0,19 3,81 E64 widia.com
