Inserts CW2015295252629525272952528–2952529–29525302952531CW2015––– CW3020––––––––CW3020––– CW5025–295215929521612952173295217429521752952176–CW5025295215829521602952162 Ceramic Inserts ISO Inserts P M ⅷ first choice K ⅷ ⅷ ࠗ alternate choice N S ⅷ H ⅷ „CNGA ISO catalogue number D L10 S R¡ D1 CNGA120404T02020 12,70 12,90 4,76 0,4 5,16 CNGA120408T02020 12,70 12,90 4,76 0,8 5,16 CNGA120412T02020 12,70 12,90 4,76 1,2 5,16 CNGA120416T02020 12,70 12,90 4,76 1,6 5,16 CNGA160612T02020 15,88 16,12 6,35 1,2 6,35 CNGA160616T02020 15,88 16,12 6,35 1,6 6,35 CNGA190612T02020 19,05 19,34 6,35 1,2 7,93 CNGA190616T02020 19,05 19,34 6,35 1,6 7,93 „CNGA-FW ISO catalogue number D L10 S R¡ D1 CNGA120408T01020FW 12,70 12,90 4,76 0,8 5,16 CNGA120412T01020FW 12,70 12,90 4,76 1,2 5,16 CNGA120416T01020FW 12,70 12,90 4,76 1,6 5,16 B178 widia.com
