High-Performance Solid Carbide End Mills High-Performance Solid Carbide End Mills • Hard Materials Series 70N6 71N6 • 37–52 HRC • Vision Plus™ X-Feed™ • Non-centre cutting. • Standard items listed. Additional styles and coatings made-to-order. End Mill Tolerances tolerance h6 D1 tolerance e8 D +/- )3 -0,014/-0,028 )3 0/0,006 > 3–6 -0,020/-0,038 > 3–6 0/0,008 > 6–10 -0,025/-0,047 > 6–10 0/0,009 > 10–18 -0,032/-0,059 > 10–18 0/0,011 > 18–30 -0,040/-0,073 > 18–30 0/0,013 „Series 70N6 71N6 • 37–52 HRC • Vision Plus X-Feed ⅷ first choice ࠗ alternate choice graAdelTAiNlT-MiNT-M1 T1 AlTiN length of cut length order # catalogue # D1 D D3 Ap1 max L3 L R¡ Rt 3745400 71N606002MT 6,0 6 5,50 0,32 9,00 57 0,38 0,62 3341346 70N606002MT 6,0 6 5,50 0,32 18,00 63 0,38 0,62 3745401 71N608003MT 8,0 8 7,50 0,42 12,00 63 0,50 0,83 3341348 70N608003MT 8,0 8 7,50 0,42 24,00 76 0,50 0,83 3745402 71N610004MT 10,0 10 9,00 0,53 15,00 72 0,63 1,04 3101466 70N610004MT 10,0 10 9,00 0,53 30,00 89 0,63 1,04 3745413 71N612005MT 12,0 12 11,00 0,63 18,00 83 0,75 1,24 3101467 70N612005MT 12,0 12 11,00 0,63 36,00 100 0,75 1,24 3484748 70N616006MT 16,0 16 15,00 0,84 48,00 110 1,00 1,66 3484749 70N620007MT 20,0 20 19,00 1,05 60,00 125 1,25 2,07 NOTE: YRC = distance from centre line to the crown of the R radius. RCN = distance from centre line to the start of the cutting edge. This dimension can also help determine the minimum circle size when helical ramping. R = the head radius size. R¡ = the shoulder radius or radius at the corner of the cutter. „Programming Data Tool List 70N6 Ramping Guide for Circular and Linear Interpolation Geometrical Parameters Circular Interpolation Linear Interpolation Allowed Range of Calculated Length (mm) per Ramp Angle Hole Diameter diameter Ap1 max Rfm Rt Rc Xfm Yfm YD Number Ramp Angle (degree) [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] flutes Smallest Largest 1 2 3 4 5 6 0,32 6 0,62 0,375 0,32 0,75 1,32 6 8,64 12 18,12 9,06 6,03 4,52 3,61 8 0,42 8 0,83 0,500 0,42 1,00 1,76 6 11,52 16 24,16 12,08 8,05 6,03 4,82 10 0,53 10 1,04 0,625 0,53 1,25 2,20 6 14,4 20 30,20 15,09 10,06 7,54 6,02 12 0,63 12 1,24 0,750 0,63 1,50 2,64 6 17,28 24 36,24 18,11 12,07 9,05 7,23 16 0,84 16 1,66 1,000 0,84 2,00 3,52 6 23,04 32 48,31 24,15 16,09 12,06 9,64 20 1,05 20 2,07 1,250 1,05 2,50 4,40 6 28,8 40 60,39 30,19 20,11 15,08 12,05 Recommended Feed 100% 70% 50% 30% 10% O152 widia.com
