High-Performance Solid Carbide End Mills High-Performance Solid Carbide End Mills • VariMill™ Series 577E • VariMill II™ ER • Victory™ Grades • Unequal flute spacing. • Centre cutting. • Optimised geometry for titanium machining. • Single tool for both roughing and finishing operations requiring fewer setups. • Standard items listed. Additional styles and coatings made-to-order. End Mill Tolerances tolerance h6 D1 tolerance e8 D +/- )3 -0,014/-0,028 )3 0/-0,006 > 3–6 -0,020/-0,038 > 3–6 0/-0,008 > 6–10 -0,025/-0,047 > 6–10 0/-0,009 > 10–18 -0,032/-0,059 > 10–18 0/-0,011 > 18–30 -0,040/-0,073 > 18–30 0/-0,013 „Series 577E • VariMill II ER • Victory Grades ⅷ first choice ࠗ alternate choice WS15PE WS15PE WS15PE AlTiN AlTiN AlTiN length of cut length order # catalogue # order # catalogue # order # catalogue # D1 D Ap1 max L R¡ 5599171 577E10004T – – 10,0 10 22,00 72 — 5599172 577E10024T – 5599173 577E10024W 10,0 10 22,00 72 0,50 – 5599174 577E12005V – 12,0 12 26,00 83 — – 5599175 577E12015V 5599176 577E12015W 12,0 12 26,00 83 0,75 – 5599177 577E16006V – 16,0 16 32,00 92 — – 5599178 577E16016V 5599179 577E16016W 16,0 16 32,00 92 0,75 – 5599180 577E20007V – 20,0 20 38,00 104 — – 5599181 577E20017V 5599182 577E20017W 20,0 20 38,00 104 0,75 – 5599183 577E25018V 5599184 577E25018W 25,0 25 45,00 121 0,75 O32 widia.com
