METRIC Single End Roughers (Fine Pitch) 40° POS 3 4 5 DIN6535 LF APMX TOLERANCES h10 (mm) DC DCON DC = +0,000 / –0,100DCON = h6 62M RE = +0,127/–0,127 RE METRIC SERIES mm EDP NO. CUTTING LENGTH OVERALL SHANK CORNER NO. OF Ti-NAMITE Ti-NAMITE-C Ti-NAMITE-A DIAMETER OF CUT LENGTH DIAMETER RADIUS FLUTES (TiN) (TiCN) (AlTiN) DC APMX LF DCON RE 6,0 19,0 63,0 6,0 1,14 3 46207 46206 46210 8,0 19,0 63,0 8,0 1,14 3 46209 46208 46211 STAINLESS STEELS 10,0 22,0 72,0 10,0 1,52 3 46213 46212 46214 HIGH TEMP ALLOYS 12,0 26,0 83,0 12,0 1,52 4 46217 46216 46218 16,0 32,0 92,0 16,0 1,52 4 46221 46220 46222 TITANIUM 20,0 38,0 104,0 20,0 1,52 4 46229 46228 46232 For patent 25,0 44,0 104,0 25,0 1,52 5 46231 46230 46233 information visitwww.ksptpatents.com www.kyocera-sEgNsDtoMoIl.LcLoSm END MILLS 209
