METRIC S-Carb® 38° POS ® 3 LF LU 43M • 43MCR DC DCONDN METRIC SERIES RE APMX CONTINUED mm EDP NO. TOLERANCES (mm) CUTTING LENGTH OVERALL SHANK CORNER REACH NECK POLISHED UNCOATED Ti-NAMITE-B 6 DIAMETER DIAMETER OF CUT LENGTH DIAMETER RADIUS LU DIAMETER FLUTE (TiB2) DC APMX LF DCON RE DN DC = +0,000/–0,008 10,0 40,0 100,0 10,0 1,0 – – • – 44859 DCON = h6 10,0 40,0 100,0 10,0 1,5 – – • – 44860 RE = +0,000/–0,050 10,0 40,0 100,0 10,0 2,0 – – • – 44861 >6–10 DIAMETER 12,0 26,0 83,0 12,0 – – – 44708 44722 DC = +0,000/–0,009 12,0 26,0 83,0 12,0 1,5 – – 44814 44733 DCON = h6RE= +0,000/–0,050 12,0 26,0 83,0 12,0 2,0 – – 44815 44826 12,0 26,0 83,0 12,0 2,5 – – 44816 44827 >10–18 DIAMETERDC= +0,000/–0,011 12,0 26,0 83,0 12,0 3,0 – – 44817 44734 DCON = h6 12,0 48,0 100,0 12,0 – – – • – 44897 RE = +0,000/–0,050 12,0 48,0 100,0 12,0 0,5 – – • – 44862 >18–20 DIAMETER 12,0 48,0 100,0 12,0 1,0 – – • – 44863 DC = +0,000/–0,013 12,0 48,0 100,0 12,0 1,5 – – • – 44864 DCON = h6 12,0 48,0 100,0 12,0 2,0 – – • – 44865 RE = +0,000/–0,050 12,0 48,0 100,0 12,0 2,5 – – • – 44866 12,0 48,0 100,0 12,0 3,0 – – • – 44867 NON-FERROUS 14,0 30,0 89,0 14,0 – – – • – 44898 PLASTICS/COMPOSITES 14,0 30,0 89,0 14,0 1,0 – – • – 44868 14,0 30,0 89,0 14,0 2,0 – – • – 44869 For patent 14,0 30,0 89,0 14,0 3,0 – – • – 44870 information visitwww.ksptpatents.com 14,0 18,0 125,0 14,0 – 45,0 13,49 • – 44899 16,0 32,0 92,0 16,0 – – – 44711 44725 16,0 32,0 92,0 16,0 1,5 – – 44818 44735 16,0 32,0 92,0 16,0 2,0 – – 44819 44828 16,0 32,0 92,0 16,0 2,5 – – 44820 44829 16,0 32,0 92,0 16,0 3,0 – – 44821 44736 16,0 32,0 92,0 16,0 4,0 – – • – 44871 16,0 64,0 125,0 16,0 – – – • – 44900 16,0 64,0 125,0 16,0 0,5 – – • – 44872 16,0 64,0 125,0 16,0 1,0 – – • – 44873 16,0 64,0 125,0 16,0 1,5 – – • – 44874 16,0 64,0 125,0 16,0 2,0 – – • – 44875 16,0 64,0 125,0 16,0 2,5 – – • – 44876 continued on next page 150 END MILLS wwwE.kNyDoMceILraLS-sgstool.com
