Общий каталог Osawa 2021 - страница 443

HF UNI SC - Variable Helix and unequal pitch - C+R CUTTING PARAMETERS INFO HF871 Material GroupISO 513 P1 P2 P7 K1 P3 P4 M1 K2 K3 P5 M2 M3 K4 S1 S4 S2 S3 S5 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ≤40 HRC ap x ae DxD DxD 0.5D x D 0.5D x D Vc (m/min) 100÷120 60÷80 45÷65 20÷40 CARBIDEDRILLS D fz fz fz fz(mm)(mm/z)(mm/z)(mm/z)(mm/z) 1 0.003 0.002 0.002 0.003 PU-HPU TA-4HTA 2 0.005 0.005 0.004 0.006 SUH DRILLINGALH 34 0.0070.009 0.0060.008 0.0060.007 0.0080.010 HRC 5 0.012 0.010 0.009 0.013 SUH MINI 6 0.014 0.012 0.011 0.015 HL 8 0.018 0.016 0.014 0.019 HSD 10 0.021 0.019 0.017 0.023 C-SD-TA 12 0.024 0.022 0.019 0.026 14 0.027 0.024 0.022 0.030 16 0.030 0.027 0.024 0.033 18 0.033 0.030 0.026 0.036 20 0.037 0.033 0.029 0.040 ap x ae ≤ D3 0.5D x D 0.5D x D 0.25D x D 0.25D x D Material Group P1 P2 P7 K1 P3 P4 M1 K2 K3 P5 M2 M3 K4 S1 S4 S2 S3 S5 ISO 513 HSS DRILLS Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ≤40 HRC ap x ae 2D x 0.2D 2D x 0.1D 1.5D x 0.1D 1.5D x 0.1D LFTA SUTA Vc (m/min) 190÷230 130÷150 100÷120 50÷70 HSS-HSS/CO D fz fz fz fz (mm) (mm/z) (mm/z) (mm/z) (mm/z) 1 0.013 0.011 0.010 0.014 2 0.025 0.023 0.020 0.028 3 0.035 0.032 0.028 0.039 TROCHOIDAL 4 0.046 0.042 0.037 0.051 5 0.058 0.052 0.046 0.063 6 0.068 0.061 0.054 0.074 CARBIDE 8 0.088 0.079 0.070 0.096 END-MILLS 10 0.105 0.095 0.084 0.116 12 0.120 0.108 0.096 0.132 G2 14 0.135 0.122 0.108 0.149 MDTA HF VH/UP 16 0.150 0.135 0.120 0.165 MEF 18 0.165 0.149 0.132 0.182 ALU 20 0.183 0.164 0.146 0.201 MEX/MHUH/MH ap x ae D1 1.5D x 0.1D 1.5D x 0.1D 1.5D x 0.1D 1.5D x 0.1D ap x ae ≤ D3 1.5D x 0.1D 1.5D x 0.1D 1.5D x 0.1D 1.5D x 0.1D NOTES: Down milling CNC programming is required. “ae” value max 0.2xD - “T” value max 0.1xD. The use of end mill with diameter 30-40% smaller than the width of the slot is recommended. The cutting conditions are based on CNC programming with medium dynamic speed. With lower CNC dynamic speed, use the same cutting conditions or reduce the cutting speed Vc. HSS With higher CNC dynamic speed, reduce the “T” value by approximately -30 -50% and apply the maximum available cutting speed Vc. END-MILLS ae R1 Cutter radius R2 Half of slot width T Programming width of cut ae Actual width of cut Y (+) Y X (+) CARBIDE BURRS T PARAMETERS SUGGESTED WITH HIGH PRECISION WELDON CHUCK AND STABLE MACHINING CONDITION. FOR APPLICATION ON HIGH POWER MILLING CHUCK, PLEASE REFER TO HF840 PARAMETERS. 442 R2 R1
