HF UNI - Variable helix - Corner radius HF643 OSAWANORM INFO weldon shank, 5 flutes ideal for trochoidal milling, corner radius CR CARBIDE DRILLS PU-HPU TA-4HTA P M K N S H SUH ALH H H H HH 1st choiceI suitable CR HRCSUH MINI HL HSD SIDE MILLING HELICAL RAMPING VERTICAL TROCHOIDAL C-SD-TA D D Tol. CR CR Tol. d(h6) l l1 L z EDP No. Stock 4 0/-0.020 0.10 0/-0.015 6 12 57 5 HF64301040 h 5 0/-0.020 0.10 0/-0.015 6 13 57 5 HF64301050 h 6 0/-0.020 0.10 0/-0.015 6 13 57 5 HF64301060 h 8 0/-0.020 0.20 0/-0.015 8 20 64 5 HF64302080 h 10 0/-0.020 0.20 0/-0.020 10 22 72 5 HF64302100 h HSS 12 0/-0.020 0.30 0/-0.020 12 26 83 5 HF64303120 h DRILLS 16 0/-0.020 0.30 0/-0.020 16 32 92 5 HF64303160 h 20 0/-0.020 0.30 0/-0.020 20 38 104 5 HF64303200 h LFTA SUTA HSS-HSS/CO CARBIDE END-MILLS G2 MDTA HF VH/UP MEF ALU MEX/MH UH/MH HSS END-MILLS CARBIDE BURRS h stock standard f non-standard stock m stock exhaustion 429
