Общий каталог Osawa 2021 - страница 320

G2 - General purpose - Square G2WS4 OSAWA <45NORMHRC INFO weldon shank, 4 flutes CARBIDE DRILLS PU-HPU TA-4HTA P M K N S H SUH ALH H I H I HRC H 1st choice I suitable SUH MINI HL HSD SIDE MILLING C-SD-TA D D Tol. C C Tol. d(h6) l l1 L z EDP No. Stock 3 0/-0.020 6 8 57 4 G2WS4030 h 4 0/-0.020 6 11 57 4 G2WS4040 h 5 0/-0.020 6 13 57 4 G2WS4050 h 6 0/-0.020 6 13 57 4 G2WS4060 h 8 0/-0.025 8 19 63 4 G2WS4080 h HSS 10 0/-0.025 10 22 72 4 G2WS4100 h DRILLS 12 0/-0.025 12 26 83 4 G2WS4120 h 14 0/-0.030 14 26 83 4 G2WS4140 h LFTA 16 0/-0.030 16 32 92 4 G2WS4160 h SUTAHSS-HSS/CO 20 0/-0.030 20 38 104 4 G2WS4200 h CARBIDE END-MILLS G2 MDTA HF VH/UP MEF ALU MEX/MH UH/MH HSS END-MILLS CARBIDE BURRS h stock standard f non-standard stock m stock exhaustion 319
