G2 - General purpose - Square CUTTING PARAMETERS INFO GB205 Material GroupISO 513 P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae 0.5D x D 0.5D x D 0.3D x D 0.5D x D Vc (m/min) 50÷60 30÷50 20÷40 70÷90 D fz(mm)(mm/z) fz(mm/z) fz(mm/z) fz(mm/z) CARBIDEDRILLS 1 0.004 0.003 0.003 0.005 SLOTTING 2 0.007 0.006 0.005 PU-HPU0.009TA-4HTA 3 0.010 0.009 0.008 0.013 SUH 4 0.014 0.012 0.011 0.018 ALH 5 0.018 0.015 0.014 0.023 HRC 6 0.023 0.020 0.017 0.030 SUH MINI 8 0.030 0.026 0.023 0.039 HL 10 0.038 0.032 0.029 0.049 HSD 12 0.045 0.038 0.034 0.059 C-SD-TA < D3 mm: ap = 0.2D Material Group P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 N1 N2 N3 N4 ISO 513 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC ap x ae 1.5D x 0.3D 1.5D x 0.3D 1.5D x 0.2D 1.5D x 0.3D Vc (m/min) 50÷60 30÷50 20÷40 70÷90 D fz fz fz fz HSS (mm) (mm/z) (mm/z) (mm/z) (mm/z) DRILLS 1 0.004 0.004 0.003 0.006 SIDE MILLING 2 0.009 0.007 0.007 0.011 LFTA 3 0.013 0.011 0.009 0.016 SUTAHSS-HSS/CO 4 0.018 0.015 0.013 0.023 5 0.023 0.019 0.017 0.029 6 0.029 0.024 0.022 0.037 8 0.038 0.032 0.028 0.049 10 0.048 0.040 0.036 0.062 12 0.056 0.048 0.042 0.073 < D3 mm: ae = 0.2D CARBIDE Material Group P1 P2 K1 P3 P4 P7 M1 K2 P5 M2 K3 END-MILLSN1N2N3N4 ISO 513 G2 Hardness/Rm ≤700 N/mm² 600÷1000 N/mm² ≤35 HRC MDTA ap x ae DxD DxD DxD DxD HF VH/UP MEF Vc (m/min) 40÷50 30÷40 20÷30 60÷80 ALU D fz fz fz fz MEX/MH (mm) (mm/z) (mm/z) (mm/z) (mm/z) UH/MH 1 0.002 0.002 0.002 0.003 DRILLING 2 0.004 0.004 0.003 0.006 3 0.006 0.005 0.005 0.008 4 0.009 0.007 0.007 0.011 5 0.011 0.010 0.008 0.015 6 0.014 0.012 0.011 0.019 8 0.019 0.016 0.014 0.024 10 0.024 0.020 0.018 0.031 HSS 12 0.028 0.024 0.021 0.037 END-MILLS < D3 mm: ap = 0.5D CARBIDE BURRS 299
