Stock DRILLING (mm) *1 DC L/D Order Number *2No.TLU LBX LPR OAL DCON DCSFMS S10 Insert Type Clamp Screw Wrench 2 MVX5000X2F40 s 2 100 107 147 212 40 63 1.6 SOoX16 TPS54 TIP25D 3 MVX5000X3F40 s 2 150 157 197 262 40 63 1.6 SOoX16 TPS54 TIP25D 50.0 44 MVX5000X4F40 s 2 200 207 247 312 40MVX5000X4F50s220020724732250631.6631.6SOoX16TPS54 TIP25DSOoX16TPS54TIP25D 5 MVX5000X5F40 s 2 250 257 297 362 40 63 1.6 SOoX16 TPS54 TIP25D 5 MVX5000X5F50 s 2 250 257 297 372 50 63 1.6 SOoX16 TPS54 TIP25D 2 MVX5100X2F40 s 2 102 109 149 214 40 63 1.5 SOoX16 TPS54 TIP25D 3 MVX5100X3F40 s 2 153 160 200 265 40 63 1.5 SOoX16 TPS54 TIP25D 51.0 44 MVX5100X4F40 s 2 204 211 251 316 40MVX5100X4F50s220421125132650631.5631.5SOoX16TPS54 TIP25DSOoX16TPS54TIP25D 5 MVX5100X5F40 s 2 255 262 302 367 40 63 1.5 SOoX16 TPS54 TIP25D 5 MVX5100X5F50 s 2 255 262 302 377 50 63 1.5 SOoX16 TPS54 TIP25D 2 MVX5200X2F40 s 2 104 111 151 216 40 63 1.39 SOoX16 TPS54 TIP25D 3 MVX5200X3F40 s 2 156 163 203 268 40 63 1.39 SOoX16 TPS54 TIP25D 52.0 44 MVX5200X4F40 s 2 208 215 255 320 40MVX5200X4F50s220821525533050631.39631.39SOoX16SOoX16TPS54TIP25DTPS54TIP25D 5 MVX5200X5F40 s 2 260 267 307 372 40 63 1.39 SOoX16 TPS54 TIP25D 5 MVX5200X5F50 s 2 260 267 307 382 50 63 1.39 SOoX16 TPS54 TIP25D 2 MVX5300X2F40 s 2 106 113 153 218 40 63 1.29 SOoX16 TPS54 TIP25D 3 MVX5300X3F40 s 2 159 166 206 271 40 63 1.29 SOoX16 TPS54 TIP25D 53.0 44 MVX5300X4F40 s 2 212 219 259 324 40MVX5300X4F50s221221925933450631.29631.29SOoX16SOoX16TPS54TIP25DTPS54TIP25D 5 MVX5300X5F40 s 2 265 272 312 377 40 63 1.29 SOoX16 TPS54 TIP25D 5 MVX5300X5F50 s 2 265 272 312 387 50 63 1.29 SOoX16 TPS54 TIP25D 2 MVX5400X2F40 s 2 108 115 155 220 40 63 1.19 SOoX16 TPS54 TIP25D 3 MVX5400X3F40 s 2 162 169 209 274 40 63 1.19 SOoX16 TPS54 TIP25D 54.0 44 MVX5400X4F40 s 2 216 223 263 328 40MVX5400X4F50s221622326333850631.19631.19SOoX16SOoX16TPS54TIP25DTPS54TIP25D 5 MVX5400X5F40 s 2 270 277 317 382 40 63 1.19 SOoX16 TPS54 TIP25D 5 MVX5400X5F50 s 2 270 277 317 392 50 63 1.19 SOoX16 TPS54 TIP25D 2 MVX5500X2F40 s 2 110 117 157 222 40 63 1.08 SOoX16 TPS54 TIP25D 3 MVX5500X3F40 s 2 165 172 212 277 40 63 1.08 SOoX16 TPS54 TIP25D 55.0 44 MVX5500X4F40 s 2 220 227 267 332 40MVX5500X4F50s222022726734250631.08631.08SOoX16SOoX16TPS54TIP25DTPS54TIP25D 5 MVX5500X5F40 s 2 275 282 322 387 40 63 1.08 SOoX16 TPS54 TIP25D 5 MVX5500X5F50 s 2 275 282 322 397 50 63 1.08 SOoX16 TPS54 TIP25D 2 MVX5600X2F40 s 2 112 119 159 224 40 63 0.98 SOoX16 TPS54 TIP25D 3 MVX5600X3F40 s 2 168 175 215 280 40 63 0.98 SOoX16 TPS54 TIP25D M 56.0 44 MVX5600X4F40 s 2 224 231 271 336 40MVX5600X4F50s222423127134650630.98630.98SOoX16SOoX16TPS54TIP25DTPS54TIP25D 5 MVX5600X5F40 s 2 280 287 327 392 40 63 0.98 SOoX16 TPS54 TIP25D 5 MVX5600X5F50 s 2 280 287 327 402 50 63 0.98 SOoX16 TPS54 TIP25D *1 Clamp Torque (lbf-in) : TPS54=66 *2 Number of Teeth CUTTING CONDITIONS M190 SPARE PARTS N001 INSERTS M189 USAGE NOTE M195 TECHNICAL DATA P001 M187
