ISOTURN TOOLS LHGAMF GAMP 50°MAX SVJCR/L-16-JHP 93° Screw Lock Tools with Channels HF H 105° for High-Pressure Coolant 4° G 1/8"-28 Carrying 35° Rhombic Insertswith 7° Clearance Angle 4° (8° Central coolant direction rotation adjustment) WF B KAPR LF Bar Max Designation H B HF LF LH WF KAPR(1) GAMP GAMF Insert SVJCR/L 2525M-16-JHP 25.0 25.0 25.0 150.00 42.0 32.00 93.0 0.0 0.0 VCMT 1604 • For user guide, see pages 78-84 (1) Tool cutting edge angle For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223) Spare Parts Designation SVJCR/L 2525M-16-JHP TVC 3-1 SR TC-3 SR 16-236 P CU-V-JHP T-15/5 HW 2.5 T-8/5 50°MAX 105° C#-SVJCR/L 7093° Bar Max Screw Lock Tools with CAMFIX Exchangeable Shanks Carrying 35° Rhombic Inserts DCONMS with 7° Clearance Angle WF LF Right-hand shown Designation DCONMS WF LF Insert CDI(1) CP(2) C4 SVJCR/L-27050-11 40.00 27.00 50.00 VC.. 1103 1 70 SR 14-560/S M2.5X0.45 T-8/5 EZ 83 C4 SVJCR/L-27050-16 40.00 27.00 50.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 83 C5 SVJCR-35060-11 50.00 35.00 60.00 VC.. 1103 1 70 SR 14-560/S M2.5X0.45 T-8/5 EZ 104 C5 SVJCR/L-35060-16 50.00 35.00 60.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 104 C6 SVJCR/L-45065-16 63.00 45.00 65.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 125 (1) 1 - Hole for data chip, 0 - Without hole for data chip (2) Coolant pressure (Bar) For inserts, see pages: VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223) GAMF 50°MAX 105° 93° Bar Max C#-SVJCR/L-JHP 4° Screw Lock Tools withCAMFIX Exchangeable Shanks ECA4° (8° Central coolant direction rotation adjustment)WFDCONMS Carrying 35° Rhombic Inserts L3 with 7° Clearance Angle LF Designation DCONMS WF LF GAMF ECA L3 Insert CDI(1) CP(2) C3 SVJCR-22040-11-JHP 32.00 22.00 40.00 0.0 55.0 - VCMT 1103 0 300 C4 SVJCR/L-27055-16-JHP 40.00 27.00 55.00 0.0 55.0 - VCMT 1604 1 300 C5 SVJCR/L-35060-16-JHP 50.00 35.00 60.00 0.0 55.0 - VCMT 1604 1 300 C6 SVJCR-45065-16-JHP 63.00 45.00 65.00 0.0 70.0 16.80 VCMT 1604 1 300 • For user guide, see pages 78-84 (1) 1 - Hole for data chip, 0 - Without hole for data chip (2) Coolant pressure (Bar) For inserts, see pages: VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223) Spare Parts Designation C3 SVJCR-22040-11-JHP SR 14-560 CH-1.9D-JHP T-8/5 C4 SVJCR/L-27055-16-JHP TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5 C5 SVJCR/L-35060-16-JHP TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP OR 6.4X0.9N T-8/5 HW 2.5 C6 SVJCR-45065-16-JHP TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5 66 ISCAR
