Каталог Iscar расточные системы 2022 - страница 70

ITS BORE IC6025 IC8250 IC6015 IC8150IC830 IC20IC6025 IC5010IC6015 IC428IC806 IC5005IC807 IC806IC907 IC807IC804 IC907 80° 99° 95º CCMT/CCGT-SM 95º 91° 95º Single-Sided Turning Inserts for Semi-Finish and Finishing on IC D1 Soft Materials and Exotic Alloys 7° RE L S Dimensions Tough 1  Hard RecommendedMachining Data ap f Designation L IC S RE D1 (mm) (mm/rev) CCGT 060201-SM 6.45 6.35 2.38 0.10 2.80 • 0.25-2.00 0.05-0.20 CCGT 060202-SM 6.45 6.35 2.38 0.20 2.80 • 0.25-2.00 0.05-0.25 CCMT 060202-SM 6.45 6.35 2.38 0.20 2.80 • • • 0.25-2.00 0.05-0.25 CCMT 060204-SM 6.45 6.35 2.38 0.40 2.80 • • • • • • • 0.50-2.50 0.07-0.25 CCMT 060208-SM 6.45 6.35 2.38 0.80 2.80 • • • • 0.50-2.50 0.07-0.25 CCMT 09T302-SM 9.70 9.52 3.97 0.20 4.40 • • • • • • 0.50-2.50 0.06-0.25 CCMT 09T304-SM 9.70 9.52 3.97 0.40 4.40 • • • • • • • • • • 0.50-2.50 0.06-0.25 CCMT 09T308-SM 9.70 9.52 3.97 0.80 4.40 • • • • • • • • • 0.50-3.00 0.07-0.25 CCMT 120404-SM 12.90 12.70 4.76 0.40 5.50 • • • • • 0.70-3.50 0.07-0.25 CCMT 120408-SM 12.90 12.70 4.76 0.80 5.50 • • • • • • 0.70-3.50 0.07-0.30 For tools, see pages: IHCR (408) • IHRF (436) • IHRF-BW (439) • IHRF-C (413) • IHRF-CH (439) • IHSR (408) • IHSR-BW (410) • IHSR-C (413) • IHSR-CH (409) 80° CCMT-PF 95º 80° Rhombic Inserts with a Positive Flank for Semi-Finish IC D1 and Finishing on Soft Materials and Exotic Alloys 7°RE L S Dimensions Tough 1  Hard RecommendedMachining Data ap f Designation L IC S RE D1 (mm) (mm/rev) CCMT 060202-PF 6.30 6.35 2.38 0.20 2.80 • • • • • • 0.20-2.50 0.04-0.25 CCMT 060204-PF 6.30 6.35 2.38 0.40 2.80 • • • • • • 0.40-2.50 0.04-0.30 CCMT 09T302-PF 9.70 9.52 3.97 0.20 4.40 • • • • • 0.50-3.00 0.05-0.30 CCMT 09T304-PF 9.70 9.52 3.97 0.40 4.40 • • • • • • • 0.50-3.50 0.05-0.35 For tools, see pages: IHCR (408) • IHRF (436) • IHRF-BW (439) • IHRF-C (413) • IHRF-CH (439) • IHSR (408) • IHSR-BW (410) • IHSR-C (413) • IHSR-CH (409) 452 ISCAR
