PARTING IC656 IC328 IC328 IC830 IC830 IC354 IC354 IC908IC908 IC20IC20 GIM-J ±0.1 Utility Single-Sided Inserts 7° for Parting and Grooving 15.3 Ref. 5 Soft Materials, Tubes and Small Diameters CW BW RE Dimensions Tough 1  Hard RecommendedMachining Data f groove Designation CW RE CWTOL(1) BW (mm/rev) GIM 2.2J 2.20 0.17 0.05 1.70 • • • • • 0.06-0.13 GIM 3J 3.00 0.25 0.05 2.40 • • • • • 0.08-0.15 GIM 4J 4.00 0.25 0.05 3.20 • • • • • 0.08-0.18 • For cutting speed recommendations and user guide, see pages 538-547 (1) Cutting width tolerance (+/-) For tools, see pages: C#-GHDR/L (274) • CGHN 26-M (356) • CGHN 32-DGM (358) • CGHN 32-M (357) • CGHN-D (283) • CGHN-DG (283) • CGHN-S (282) • CGPAD (281) • CGPAD-JHP (282) • GHDR/L (short pocket) (275) • GHDR/L-JHP (short pocket) (276) • GHDR/L-JHP-MC (short pocket) (277) • GHGR/L (278) • GHMPR/L (273) • GHMR/L (273) • GHSR/L (373) • GHSR/L-JHP-SL (374) • NQCH-GHSR/L-JHP (374) ±0.1 GIM-J-RA/LA 7° Utility Single-Sided Inserts 515.3 Ref. for Parting and GroovingSoft Materials, Parting Tubesand Small Diameters RE RAPSIRRBW CW LA Dimensions Tough 1  Hard RecommendedMachining Data f groove Designation CW RE CWTOL(1) PSIRL PSIRR BW (mm/rev) GIM 2.2J-8LA 2.20 0.17 0.05 8.0 - 1.70 • • • • 0.05-0.10 GIM 2.2J-8RA 2.20 0.17 0.05 - 8.0 1.70 • • • • • • 0.05-0.10 GIM 2.2JS-15LA 2.20 0.02 0.05 15.0 - 1.70 • • • 0.05-0.10 GIM 2.2JS-15RA 2.20 0.02 0.05 - 15.0 1.70 • • • • • 0.05-0.10 GIM 3J-4LA 3.00 0.22 0.05 4.0 - 2.40 • • 0.05-0.12 GIM 3J-4RA 3.00 0.25 0.05 - 4.0 2.40 • • • • 0.05-0.12 GIM 3J-8LA 3.00 0.25 0.05 8.0 - 2.40 • • • • 0.05-0.12 GIM 3J-8RA 3.00 0.25 0.05 - 8.0 2.40 • • • • • • 0.05-0.12 GIM 3JS-15LA 3.00 0.02 0.05 15.0 - 2.40 • • • 0.05-0.12 GIM 3JS-15RA 3.00 0.02 0.05 - 15.0 2.40 • • • • 0.05-0.12 GIM 4J-6LA 4.00 0.25 0.05 6.0 - 3.20 • 0.08-0.15 GIM 4J-6RA 4.00 0.25 0.05 - 6.0 3.20 • • 0.08-0.15 • For cutting speed recommendations and user guide, see pages 538-547 (1) Cutting width tolerance (+/-) For tools, see pages: C#-GHDR/L (274) • CGHN 26-M (356) • CGHN 32-DGM (358) • CGHN 32-M (357) • CGHN-D (283) • CGHN-DG (283) • CGHN-S (282) • CGPAD (281) • CGPAD-JHP (282) • GHDR/L (short pocket) (275) • GHDR/L-JHP (short pocket) (276) • GHDR/L-JHP-MC (short pocket) (277) • GHGR/L (278) • GHMPR/L (273) • GHMR/L (273) • GHSR/L (373) • GHSR/L-JHP-SL (374) • NQCH-GHSR/L-JHP (374) 522 ISCAR
