PARTING IC1028IC1028 IC1008IC1008 GFT-J Thin Parting, Grooving and Slitting Single-Ended Inserts for Soft Materials CW RE Dimensions Tough 1  Hard Recommended Machining Data f groove Designation CW RE (mm/rev) GFT 0.6J-0.1 0.60 0.10 • • 0.03-0.05 GFT 0.8J-0.1 0.80 0.10 • • 0.03-0.07 GFT 1.0J-0.1 1.00 0.10 • • 0.03-0.09 GFT 1.2J-0.14 1.20 0.14 • • 0.03-0.10 GFT 1.6J-0.16 1.60 0.16 • • 0.03-0.12 For tools, see pages: ADMP D22 (519) • SGAQ (376) GFT-C Thin Parting, Grooving & Slitting Single-Ended Inserts for Soft Materials CW RE Dimensions Tough 1  Hard Recommended Machining Data f groove Designation CW RE (mm/rev) GFT 1.6C-0.16 1.60 0.16 • • 0.05-0.15 For tools, see pages: ADMP D22 (519) OAL CUTDIA CNT (typx3) H Bar Max HF THMPR/L D45-JHP HBH Holders with High-Pressure HBL Coolant Channels for Pentagonal WF B TANG-GRIP Adapters Designation H HF HBH B WF CUTDIA OAL HBL CNT THMPR/L 20-D45-JHP 20.0 20.1 18.0 20.0 17.35 45.0 135.00 35.6 G1/8 THMPR/L 25-D45-JHP 25.0 25.1 13.0 25.0 22.35 45.0 135.00 35.6 G1/8 For tools, see pages: ADMP D45 (521) Spare Parts Designation THMPR/L D45-JHP SR M3X8 ISO 14580 BLACK T-10/5 PLG G1/8 TL360 HW 5.0 520 ISCAR
