ENDMILLS • SOLID CARBIDE • MULTI-MASTER MM CAB-T-T THSZMS DRVS THSZWS MULTI-MASTER Shank Extensions BD LF Designation BD THSZMS THSZWS LF DRVS(1) kg MM CAB T05T05-25/1.0-C 7.60 T05 T05 25.40 6.0 0.02 MM CAB T06T06-25/1.0-C 9.30 T06 T06 25.40 8.0 0.02 MM CAB T08T08-25/1.0-C 11.50 T08 T08 25.40 10.0 0.02 MM CAB T10T10-38/1.5-C 15.20 T10 T10 38.10 13.0 0.08 MM CAB T12T12-38/1.5-C 18.45 T12 T12 38.10 16.0 0.11 MM CAB T15T15-45/1.77-C 23.90 T15 T15 45.00 20.0 0.21 • Clamping key should be ordered separately • For adaptation, see page 44 (1) Clamping wrench size MM Adjustable 12 Torque Keys 3 Adjustable Torque Handle and Keys for Secure and 4 Accurate Tightening of 5 MULTI-MASTER Milling Heads Designation Fig. Ts(1) Key TQ(2) TORQUE WRENCH 5-50Nm 9X12 1 - - - MM WRENCH 6-05 2 T05 - 7.0 MM WRENCH 8-06 2 T06 - 10.0 MM WRENCH 10-08 2 T08 - 15.0 MM WRENCH 13-10 2 T10 - 28.0 MM WRENCH 16-12 2 T12 - 28.0 MM WRENCH 20-15 2 T15 - 40.0 MM WRENCH 4E-05 3 T05 - 7.0 MM WRENCH 5E-06 3 T06 - 10.0 MM WRENCH 7E-08 3 T08 - 15.0 MM WRENCH 8E-10 3 T10 - 28.0 MM WRENCH 9E-12 3 T12 - 28.0 INSERT TOOL 3/8" 9X12mm 4 - - - BIT SOCKET T20 3/8" DRIVE 5 - Torx T20 - BIT SOCKET T25 3/8" DRIVE 5 - Torx T25 - BIT SOCKET T30 3/8" DRIVE 5 - Torx T30 - BIT SOCKET T40 3/8" DRIVE 5 - Torx T40 - BIT SOCKET T50 3/8" DRIVE 5 - Torx T50 - • NOTE: For recommended clamping torque for each MULTI-MASTER connection size, see page 92 (1) MULTI-MASTER connection size (2) Clamping torque Nxm Adjustable Torque Handle with Interchangeable Wrenches for Clamping MULTI-MASTER Milling Heads The adjustable torque handle, interchangeable wrenches and Torx bits are optional and should be ordered separately. 91
