IC908 IC903 IC908 ENDMILLS • SOLID CARBIDE • MULTI-MASTER TP THSZMS MT-W-MM DC Carbide Milling Heads with a Threaded Connection forInternal and External 55° APMX Application: General engineeringLFfittings and pipe couplings BSW Thread Profile TP NUT Dimensions 55˚ RE=0.137TP SCREW Designation TPI(1) TDZ DC NOF(2) APMX LF THSZMS TP(3) MT 10D6 19W-MMT05 19.0 G1/4-3/8 10.00 4 5.30 12.75 T05 1.337 • MT 16D13 14W-MMT08 14.0 G1/2-7/8 16.00 4 12.70 20.00 T08 1.814 • MT 16D11 11W-MMT08 11.0 G=>1 16.00 4 11.50 20.00 T08 2.309 • MT20F15 14W-MMTT10 14.0 G3/4-7/8 20.00 6 12.70 21.00 T10 1.814 • MT20F14 11W-MMTT10 11.0 G=>1 20.00 6 11.50 21.00 T10 2.309 • • Note: Description and dimensions relate to the new products with clamping flats. There is a possibility that the customer will receive the old item (with TORX) until the stock is depleted. • For shanks, see pages 84-91 • For clamping keys (should be ordered separately), tightening torques and clamping instructions, see pages 91-92 • Do not apply lubricant to the threaded connection (1) Threads per inch (2) Number of flutes (3) Thread pitch Thread Size Key (1) Torque Wrench (1) Wrench (1) Tightening Torque (Nxcm) T05 MM KEY 6x4 TORQUE WRENCH 5-50Nm 9X12 MM WRENCH 6-05 700 T06 MM KEY 8x5 TORQUE WRENCH 5-50Nm 9X12 MM WRENCH 8-06 1000 T08 MM KEY 10x7 TORQUE WRENCH 5-50Nm 9X12 MM WRENCH 10-08 1500 T10 MM KEY 13x8 TORQUE WRENCH 5-50Nm 9X12 MM WRENCH 13-10 2800 (1) Order separately KAPR THSZMS Rd° MM FF DC DCONMS Interchangeable 2 Flute FEEDMILL Solid Carbide Heads for Milling atVery Fast Feeds and Small D.O.C. Rg APMXLF ECONOMICAL SOLUTION Dimensions Tough 1  Hard RecommendedMachining Data fz Designation DC NOF(1) APMX Rg(2) THSZMS DCONMS LF KAPR(3) RMPX°(4) (mm/t) MM FF100R1.5-L12-2T06 10.00 2 0.60 2.00 T06 9.60 12.50 97.0 7.0 • 0.30-0.60 MM FF120R2.0-2T08 12.00 2 0.68 2.50 T08 11.50 11.10 97.0 7.0 • • 0.50-1.00 MM FF500R08-L59-2T08 12.70 2 0.68 2.50 T08 11.50 15.00 95.0 7.0 • 0.50-1.00 MM FF160R2.0-2T10 16.00 2 1.10 3.00 T10 15.20 13.50 97.0 7.0 • 0.55-1.10 MM FF200R2.0-2T12 20.00 2 1.50 3.40 T12 18.45 17.40 95.0 7.0 • 0.75-1.50 • For shanks, see pages 84-91 • For clamping keys (should be ordered separately), tightening torques and clamping instructions, see pages 91-92 • Do not apply lubricant to the threaded connection. • For user guide see pages 44, 177-184 (1) Number of flutes (2) Radius for programming (3) Tool cutting edge angle (4) Maximum ramping angle Machining Example: Machining Example: Shank: MM S-B-L140-C16-T08 Shank: MM S-A-L070-W20-T10 Milling head: MM FF 120R2.0-2T08 Milling head: MM FF160R2.0-2T10 908 Workpiece material: SAE 4340 HRc 28 Workpiece material: P20 HRc 52 Plunging Milling Milling ap = 2 mm ap = 0.7 mm ap = 0.2 mm Vc = 80 mm ae = 8 mm ae = 6 mm F = 0.24 m/min Vc = 150 m/min Vc = 150 m/min Fz = 1 mm/tooth Fz = 1.4 mm/tooth Vf = 7960 mm/min Vf = 8355 T = 60 min 67
