Grades CT3000 TT9080 PART SERIES SERIES TQS27 PFOARUTRSCEORRIENSER CARBIDE OR CERMET INSERT WITH FLAT CUTTING EDGE FOR HIGH QUALITY SURFACE FINISH Ø1.063" W±.0008" Repeatability ±.001" .157" Designatiaosndf W R Tmax(inch)(inch)K°Dmax Dmax Dmax Dmax Dmax Dmax Dmax Dmax Dmax≤.118≤.138≤.157≤.177≤.197≤.217≤.236≤.244≤.252 TQS27-1.50-0.20 0.059 0.008 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - PTlaQcSe2h7-o2l.d00e-r0.20 0.079 0.008 0.252 - N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQS27-2.39-0.15 0.094 0.006 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQS27-2.50-0.20 0.098 0.008 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQS27-3.00-0.20 0.118 0.008 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.17 =P =M =K =N =S =H 281
