Grades TT9080 PART SERIES SERIES TQC27 PFOARUTRSCEORRIENSER CARBIDE INSERT FOR PARTING & GROOVING @ HIGH FEED RATES Ø1.063" W±.0008" Repeatability ±.001" .157" Designatiaosndf W R Tmax(inch)(inch)K°Dmax Dmax Dmax Dmax Dmax Dmax Dmax Dmax Dmax≤.118≤.138≤.157≤.177≤.197≤.217≤.236≤.244≤.252 TQC27-1.50-0.10 0.059 0.002 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - PTlaQcCe2h7o-1l.d50e-r0.20 0.059 0.008 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-1.50-15L 0.059 0.004 0.197 15 N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-1.50-15R 0.059 0.004 0.197 15 N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-1.50-6L 0.059 0.004 0.197 6 N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-1.50-6L 0.059 0.004 0.197 6 N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-1.57-0.79 0.062 0.031 0.118 - N.L. - - - - - - - - TQC27-1.57-0.79 0.062 0.031 0.118 - N.L. - - - - - - - - TQC27-1.75-0.10 0.069 0.004 0.118 - N.L. - - - - - - - - TQC27-1.75-0.20 0.069 0.008 0.118 - N.L. - - - - - - - - TQC27-1.78-0.18 0.070 0.007 0.118 - N.L. - - - - - - - - TQC27-1.85-0.20 0.073 0.008 0.118 - N.L. - - - - - - - - TQC27-1.96-0.15 0.077 0.006 0.118 - N.L. - - - - - - - - TQC27-2.00-0.10 0.079 0.004 0.252 - N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQC27-2.00-0.20 0.079 0.008 0.252 - N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQC27-2.00-1.00 0.079 0.039 0.118 - N.L. - - - - - - - - TQC27-2.00-15L 0.079 0.004 0.252 15 N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQC27-2.00-15R 0.079 0.004 0.252 15 N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQC27-2.00-6L 0.079 0.004 0.252 6 N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQC27-2.00-6R 0.079 0.004 0.252 6 N.L. 23.62 11.02 7.09 5.12 4.13 2.36 1.97 1.18 TQC27-2.22-0.15 0.087 0.006 0.138 - N.L. 23.62 - - - - - - - TQC27-2.30-0.20 0.091 0.008 0.138 - N.L. 23.62 - - - - - - - TQC27-2.39-0.15 0.094 0.006 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-2.39-1.20 0.094 0.047 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-2.47-0.20 0.097 0.008 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-2.50-0.10 0.098 0.004 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-2.50-0.30 0.098 0.012 0.197 - N.L. 23.62 11.02 7.09 5.12 - - - - TQC27-2.70-0.10 0.106 0.004 0.224 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 - TQC27-2.87-0.20 0.113 0.008 0.224 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 - TQC27-3.00-0.00 0.118 - 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.17 TQC27-3.00-0.20 0.118 0.008 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.17 TQC27-3.00-0.30 0.118 0.012 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.17 TQC27-3.00-0.40 0.118 0.016 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.17 TQC27-3.00-1.50 0.118 0.059 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.17 TQC27-3.15-0.15 0.124 0.006 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.68 TQC27-3.18-0.20 0.125 0.008 0.252 - N.L. 23.62 11.02 7.09 5.31 4.13 3.35 3.07 2.68 =P =M =K =N =S =H 280
