PART SERIES SERIES TTER/L-TB PLOANRTGSTEMRAIEXSHOLDERS FOR EXTERNAL TURNING AND GROOVING, HIGH PRESSURE COOLANT L1 L2 H H 1/8-27 NPTF H4 A Tmax 1/8-27 NPTF B f Designation InsertSeatSize F(inch) L(inch) H(inch) H4(inch) B(inch) L2(inch) Tmax(inch) A(inch) TTEL25.4-3T25-TB 3 0.953 6.00 1.000 0.157 1.000 2.000 0.980 0.094 PTlaTEcRe2h5o.4ld-3eTr25-TB 3 0.953 6.00 1.000 0.157 1.000 2.000 0.980 0.094 TTEL25.4-4T25-TB 4 0.940 6.00 1.000 0.157 1.000 2.165 0.980 0.118 TTER25.4-4T25-TB 4 0.940 6.00 1.000 0.157 1.000 2.165 0.980 0.118 TTEL25.4-5T32-TB 5 0.925 6.00 1.000 - 1.000 2.322 1.260 0.156 TTER25.4-5T32-TB 5 0.925 6.00 1.000 - 1.000 2.322 1.260 0.156 TTEL25.4-6T32-TB 6 0.906 6.00 1.000 0.276 1.000 2.441 1.260 0.197 TTER25.4-6T32-TB 6 0.906 6.00 1.000 0.276 1.000 2.441 1.260 0.197 HARDWARE Insert Clamp Screw Clamp Screw Wrench Inlet Plug Wrench Inlet Plug Sealing Screw TTEL25.4-3T25-TB SHM5X0.8X20 L-W4 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTER25.4-3T25-TB SHM5X0.8X20 L-W4 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTEL25.4-4T25-TB SHM6X1X20 L-W5 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTER25.4-4T25-TB SHM6X1X20 L-W5 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTEL25.4-5T32-TB SHM6X1X20 L-W5 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTER25.4-5T32-TB SHM6X1X20 L-W5 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTEL25.4-6T32-TB SHM8X1.25X20 L-W6 L-W3/16 NPTF1/8 SS-M4X0.7X4 TTER25.4-6T32-TB SHM8X1.25X20 L-W6 L-W3/16 NPTF1/8 SS-M4X0.7X4 274
