PART SERIES SERIES DJ 5:1 PSOARLITDSCERAIREBSIDE DRILLS 5:1 GEOMETRY WITH EXTERNAL COOLANT D1 D1 D2 L1 L2 L3 Max. Diam. Max. Diam. Shank Maximum Flute Overall L5 Part Number Of Spot (inch) Of Spot (mm) Size/Style Depth of Cut Length Length DJ0300023T7R01 IN2005 0.118 3.00mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.50mm PDlaJc0e3h1o00ld2e3Tr7R01 IN2005 0.122 3.10mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.50mm DJ0320023T7R01 IN2005 0.126 3.20mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.50mm DJ0330023T7R01 IN2005 0.130 3.30mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.50mm DJ0340023T7R01 IN2005 0.134 3.40mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.50mm DJ0350023T7R01 IN2005 0.138 3.50mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.60mm DJ0360023T7R01 IN2005 0.142 3.60mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.60mm DJ0370023T7R01 IN2005 0.146 3.70mm 6mm Cylind. 23.00mm 28.00mm 66.00mm 0.60mm DJ0380029T7R01 IN2005 0.150 3.80mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.60mm DJ0390029T7R01 IN2005 0.154 3.90mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.60mm DJ0400029T7R01 IN2005 0.157 4.00mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.60mm DJ0410029T7R01 IN2005 0.161 4.10mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.70mm DJ0420029T7R01 IN2005 0.165 4.20mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.70mm DJ0430029T7R01 IN2005 0.169 4.30mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.70mm DJ0440029T7R01 IN2005 0.173 4.40mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.70mm DJ0450029T7R01 IN2005 0.177 4.50mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.70mm DJ0460029T7R01 IN2005 0.181 4.60mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.70mm DJ0470029T7R01 IN2005 0.185 4.70mm 6mm Cylind. 29.00mm 36.00mm 74.00mm 0.80mm DJ0480035T7R01 IN2005 0.189 4.80mm 6mm Cylind. 35.00mm 44.00mm 74.00mm 0.80mm DJ0490035T7R01 IN2005 0.193 4.90mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.80mm DJ0500035T7R01 IN2005 0.197 5.00mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.80mm DJ0510035T7R01 IN2005 0.201 5.10mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.80mm DJ0520035T7R01 IN2005 0.209 5.20mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.80mm DJ0535035T7R01 IN2005 0.205 5.30mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.80mm DJ0540035T7R01 IN2005 0.213 5.40mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.80mm DJ0550035T7R01 IN2005 0.217 5.50mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.90mm DJ0560035T7R01 IN2005 0.220 5.60mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.90mm DJ0570035T7R01 IN2005 0.224 5.70mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.90mm DJ0580035T7R01 IN2005 0.228 5.80mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.90mm DJ0590035T7R01 IN2005 0.232 5.90mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.90mm DJ0610035T7R01 IN2005 0.236 6.00mm 6mm Cylind. 35.00mm 44.00mm 82.00mm 0.90mm DJ0610043T0R01 IN2005 0.240 6.10mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.00mm DJ0620043T0R01 IN2005 0.244 6.20mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.00mm DJ0630043T0R01 IN2005 0.248 6.30mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.00mm DJ0640043T0R01 IN2005 0.252 6.40mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.00mm DJ0650043T0R01 IN2000 0.256 6.50mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.00mm DJ0660043T0R01 IN2005 0.260 6.60mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.00mm DJ0670043T0R01 IN2005 0.264 6.70mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.10mm DJ0680043T0R01 IN2005 0.268 6.80mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.10mm DJ0690043T0R01 IN2005 0.272 6.90mm 8mm Cylind. 43.00mm 53.00mm 91.00mm 1.10mm 114
