Grade CT3000 PV3010 TT1300 TT5030 TT5100 TT7310 TT8020 TT8115 TT8125 TT9225 VBMT MT CHIPBREAKER POSITIVE 5° CLEARANCE 35 DEGREE RHOMBIC INSERTS FOR MEDIUM MACHINING 35° d D1 R l 5°t ANSI ISO feed ap l d t R D1 Number Number (ipr) (inch) VBMT331MT VBMT160404MT .006 (.004-.010) .039 (.024-.118) 0.614 0.375 0.187 0.016 0.173 VBMT332MT VBMT160408MT .007 (.005-.012) .059 (.035-.118) 0.575 0.375 0.187 0.031 0.173 VBMT333MT VBMT160412MT .009 (.006-.012) .059 (.047-.118) 0.535 0.375 0.187 0.047 0.173 For use in holders SVJBR/L, S-SVQBR/L, see pages 1078, 1134. Part Number VBMT331MT VBMT332MT VBMT333MT =P =M =K =N =S =H 989
