h1 STGCR-SH EXTERNAL TOOL HOLDER WITH SCREW CLAMPING AND SHORT HEAD FOR POSITIVE 60° TC__ INSERTS f b 91° l h h Designation h b l f h1 Inch STGCR06-2C-SH 0.375 0.375 5.000 0.375 0.079 STGCR08-2C-SH 0.500 0.500 5.000 0.500 - STGCR10-2C-SH 0.625 0.625 5.000 0.625 - Metric STGCR1010K11-SH 10mm 10mm 125mm 10mm 2mm STGCR1212K11-SH 12mm 12mm 125mm 12mm - STGCR1616K11-SH 16mm 16mm 125mm 16mm - For inserts, see page 978. HARDWARE Accepts Insert Series Insert Screw Torx Driver Inch STGCR06-2C-SH TC_T22_ SM25-065-70 DS-T07F STGCR08-2C-SH TC_T22_ SM25-065-70 DS-T07F STGCR10-2C-SH TC_T22_ SM25-065-70 DS-T07F Metric STGCR1010K11-SH TC_T22_ SM25-065-70 DS-T07F STGCR1212K11-SH TC_T22_ SM25-065-70 DS-T07F STGCR1616K11-SH TC_T22_ SM25-065-70 DS-T07F 1077
