ACCESSORIES FOR TOOLHOLDERS HSK COOLANT TUBES Size(mm) Order No. 100-00-001 100-00-002 Model 7771 _ _ _ vCvw\\\\\\\v a TU -HSK63 HSK63 M18x1 TU-HSK100 HSK100 M24x1.5 1° i shank 11.5 15.5 12 16 " O 36.6 44.2 L1 L2 HSK COOLANT TUBE WRENCH Order No. Model 100-00-003 100-00-004 W-HSK63 4 shank J HSK63 HSK 100 W-HSK 100 SHRINK FIT CHUCK EXTENSION • Used in shrink fit chuck ,hydraulic chuck and power milling chuck. • For clamping cutting tools with cylinderic shank tolerance h6. • Fit for high frequency heating maching . • Avoid vibrations in the clamping system,resulting in increasing surface quality and tool life time. Size (mm) Order No. Model 100-00-005 100-00-006 100-00-007 100-00-008 100-00-009 100-00-010 100-00-011 100-00-012 100-00-013 100-00-014 100-00-015 100-00-016 100-00-017 100-00-018 100-00-019 100-00-020 100-00-021 100-00-022 100-00-023 100-00-024 C12-SFX03-160 C12-SFX04-160 C16-SFX03-160 C16-SFX04-160 C16-SFX05-160 C20-SFX05-160 C16-SFX06-160 C20-SFX06-160 C20-SF08-160 C25-SF08-160 C25-SF10-160 C25-SF12-160 C 25-SF14-160 C25-SF16-160 C32-SF10-160 C32-SF12-160 C32-SF14-160 C32-SF16-160 C32-SF18-160 C32-SF20-160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 160 ER COLLET CHUCK EXTENTION • Used in ER collet chuck ,power milling chuck. • For clamping cutting tools with cylinderic shank . Size(mm) Order No. Model 100-00-025 100-00-026 100-00-027 100-00-028 100-00-029 100-00-030 100-00-031 100-00-032 100-00-033 100-00-034 100-00-035 C16-ER 11-50( M) C 16-ER11-100(M) C20-ER16-50(M) C 20-ER16-100(M) C20-ER16-150(M) C20-ER20-50( M) C20-ER20-100(M) C20-ER 20-150(M) C25-ER20-50( M) C 25-ER 20-100(M) C25-ER20-150(M) Nuts Screw CNM11 CNM11 CNM16 CNM16 CNM16 CNM20 CNM20 CNM20 CNM20 CNM20 CNM20 S006014C S006014C S006014C S006014C S006014C S008014C S008014C S008014C S008014C S008014C S008014C dm 0.5-7 0.5-7 0.5-10 0.5-10 0.5-10 1.0-13 1.0-13 1.0-13 1.0-13 1.0-13 1.0-13 16 16 23 23 23 28 28 28 28 28 28 16 16 20 20 20 20 20 20 25 25 25 50 100 50 100 150 50 100 150 50 100 150 77 127 85 135 185 88 138 188 88 138 188 for Wrench Collets ER11 ER11 ER16 ER16 ER16 ER20 ER20 ER20 ER20 ER20 ER20 WM11 WM11 WM16 WM16 WM16 WM20 WM20 WM20 WM20 WM20 WM20
