SK DIN 69871 ( ISO 7388-1) TOOL HOLDERS REDUCING SLEEVE FOR HYDRAULIC EXPANSIONS CHUCK • Radial run-out less than 5p. • For clamping cutting tools with cylinderic shank tolerance h6. ( 11 O s C2) I I 4sr L1 L Size (mm) Order No . Model 100-01-001 100-01-002 100-01- 003 100-01-004 100-01- 005 100-01- 006 100-01-007 100-01- 008 100-01- 009 100-01-010 100-01-011 100-01-012 100-01-013 100-01-014 100-01- 015 100-01-016 100-01-017 100-01-018 100-01- 019 100-01-020 100-01- 021 100-01-022 100-01-023 100-01-024 100-01- 025 100-01- 026 100-01- 027 100-01- 028 HC12-3 HC12-4 HC12-5 HC12-6 HC12-8 HC20-3 HC20-4 HC20-5 HC20-6 HC20-7 HC20-8 HC20-9 HC20-10 HC20-11 HC 20-12 HC20-13 HC 20-14 HC20-15 HC 20-16 HC32-6 HC32-8 HC32-10 HC32-12 HC32-14 HC32-16 HC32-18 HC32-20 HC32-25 dm 3 4 5 6 8 3 4 5 6 7 8 9 10 11 12 13 14 15 16 6 8 10 12 14 16 18 20 25 L 16.5 16.5 16.5 24 25.5 17.5 17.5 17.5 25.5 28 28 32.5 32.5 36 36 36.5 37 37 37.5 25.5 27.5 30.5 30.5 32.5 40.5 40.5 40.5 48.5 12 12 12 12 12 20 20 20 20 20 20 20 20 20 20 20 20 20 20 32 32 32 32 32 32 32 32 32 47.5 47.5 47.5 47.5 47.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 52.5 63.5 63.5 63.5 63.5 63.5 63.5 63.5 63.5 63.5 HYDRAULIC EXPANSIONS CHUCK SET • each set includding 1 pc each of SK 40-AD hydraulic expansion chuck ,HC20-6 ,HC20-8 ,HC20-10,HC20-12,HC20-16 ( internal dia :6,8,10 ,12,16mm) reducing sleeve and screw wrench ,pack in strong aluminium box. ORDER NO.132-01-S 04- www. harlingentools . com
