Threading · Gewindebearbeitung Solid carbide taps and cutter · Vollhartmetall-Gewindebohrer, -fräser 4202A Tap for aluminum alloy machiningGewindebohrer zur Bearbeitung von Aluminiumlegierungen a A a B ISO 2 (6H) (6HX) Basic dimension(mm) Grade Coredrill Basis Abmessungen Number Sorte Kernbohrer Type of teeth Typ Taperlengthd1 P d2 d3 l1Anschnitt-l2 Thread-l3a×aprofileGewinde-GeometryAusführungZähne-anzahlYK40Fd länge profil 4202A-M3*0.5-6H 3P ○ 4202A-M3*0.5-6HX 3P M3 0.5 3.5 2.3 56 11 18 2.7 60° A ○3 2.5 4202AS-M3*0.5-6H 1.5P ○ 4202AS-M3*0.5-6HX 1.5P ○ 4202A-M4*0.7-6H 3P ○ 4202A-M4*0.7-6HX 3P M4 0.7 4.5 3.1 63 13 21 3.4 60° A ○3 3.3 4202AS-M4*0.7-6H 1.5P ○ 4202AS-M4*0.7-6HX 1.5P ○ 4202A-M5*0.8-6H 3P ○ 4202A-M5*0.8-6HX 3P M5 0.8 6 4 70 16 25 4.9 60° A ○3 4.2 4202AS-M5*0.8-6H 1.5P ○ 4202AS-M5*0.8-6HX 1.5P ○ C 4202A-M6*0.75-6H 3P4202A-M6*0.75-6HX3PM60.75 6 5 80 19 30 4.9 60° ○A○3 5.25 4202AS-M6*0.75-6H 1.5P ○ 4202AS-M6*0.75-6HX 1.5P ○ 4202A-M6*1-6H 3P ○ 4202AC-M6*1-6H 3P ○ 4202A-M6*1-6HX 3P M6 1 6 4.7 80 19 30 4.9 60° A ○3 5 4202AS-M6*1-6H 1.5P ○ 4202ACS-M6*1-6H 1.5P ○ 4202AS-M6*1-6HX 1.5P ○ 4202A-M7*1-6H 3P M7 1 7 5.7 80 19 30 5.5 60° A ●3 6 4202AS-M7*1-6H 1.5P ● 4202A-M8*1-6H 3P M8 1 8 6.7 90 20 35 6.2 60° A ●3 7 4202AS-M8*1-6H 1.5P ● ● Ex Stock / ab Lager ○ On demand / auf Anfrage C 166 Solid carbide drills Vollhartmetallbohrer
