Milling · Fräsen
Solid Carbide end mills · Vollhartmetallschaftfräser

2-flute conical neck ball nose end mills
2-Schneiden Mikro Kugelkopffräser mit konischem Hals
PM-2BC A2 R


d1


D
d
10° H


A1
l1
l2
L


Le
Coated
30o R R±0.005 R>0.5
Nano-AITiN D 0~-0.015
R±0.01 R≥0.5
Q
Dimension(mm) Grade


<
Abmessungen Q = Le
Type Teeth Sorte
Zähne
Typ KMG
D R A1 H l2 l1 A2 d1 L d Z 0.5° 1° 2° 3°
405

B
PM-2BC05-R0.50-M10 10 6.1° 1.08 60 2 10.4 10.9 12.2 13.9 ●
PM-2BC05-R0.50-M15 15 5.1° 1.16 60 2 15.4 16.2 18.2 20.7 ●
PM-2BC05-R0.50-M20 0.5 o
20 4.4° 1.25 70 2 20.4 21.5 24.1 27.4 ●
PM-2BC05-R0.50-M25 25 3.8° 1.34 70 2 25.4 26.8 30.0 34.2 ○
PM-2BC05-R0.50-M30 30 3.4° 1.42 70 2 30.4 32.0 35.9 41.0 ●
PM-2BC10-R0.50-M10 10 6.2° 1.21 60 2 - 10.5 11.8 13.4 ●
PM-2BC10-R0.50-M15 15 5.2° 1.38 60 2 - 15.5 17.4 19.8 ○


Vollhartmetallschaftfräser
PM-2BC10-R0.50-M20 20 4.5° 1.56 70 2 - 20.5 23.0 26.2 ●


Solid Carbide end mills
1.0o
PM-2BC10-R0.50-M25 25 3.9° 1.73 70 2 - 25.5 28.6 32.6 ○
1.0 0.50 1.0 2.5 6
PM-2BC10-R0.50-M30 30 3.5° 1.91 70 2 - 30.5 34.2 39.0 ○
PM-2BC10-R0.50-M35 35 3.2° 2.08 80 2 - 35.5 39.8 45.4 ●
PM-2BC15-R0.50-M10 10 6.3° 1.34 60 2 - - 11.3 12.8 ●
PM-2BC15-R0.50-M15 1.5o 15 5.3° 1.60 60 2 - - 16.6 18.9 ●
PM-2BC15-R0.50-M20 20 4.6° 1.86 70 2 - - 21.9 24.9 ●
PM-2BC20-R0.50-M15 15 5.4° 1.82 60 2 - - 15.8 18.0 ○
2o
PM-2BC20-R0.50-M20 20 4.7° 2.17 70 2 - - 20.8 23.7 ○
PM-2BC30-R0.50-M20 3o 20 5.0° 2.78 70 2 - - - 21.2 ○
PM-2BC50-R0.50-M20 5o 20 5.7° 4.01 70 2 - - - - ○
PM-2BC05-R0.60-M12 12 5.6° 1.31 60 2 12.4 13.1 14.6 16.6 ●
0.5o
PM-2BC05-R0.60-M24 24 3.8° 1.52 70 2 24.4 25.7 28.8 32.8 ○
PM-2BC10-R0.60-M12 12 5.7° 1.47 60 2 - 12.5 14.0 15.9 ○
1.2 0.60 1.0o 1.2 2.7 6
PM-2BC10-R0.60-M24 24 3.9° 1.89 70 2 - 24.5 27.5 31.3 ○
PM-2BC15-R0.60-M12 12 5.8° 1.63 60 2 - - 13.4 15.2 ●
1.5o
PM-2BC15-R0.60-M24 24 4.1° 2.26 70 2 - - 26.2 29.8 ○

= Very suitable · Sehr empfohlen
Material Overview · Material Übersicht = Suitable · Empfohlen
Workpiece material
KMG405


Werkstückstoff
Quenched and
Hardened steel ·
tempered steel · Cast iron,
Gehärteter Stahl Stainless Heat resist
Carbon steel Alloy steel Vergüteter Stahl Nodular Copper Aluminum Titanium
steel · alloy
Kohlenstoff Legierter cast iron alloy alloy alloy
Rostfreier warmfeste
Stahl Stahl Grauguss Kupfer Leg Alu Leg Titan Leg
~40HRC ~50HRC ~55HRC ~68HRC Stahl Leg
GGG

        

Code key B252,B254 Cutting data B286-B289 Graphics identification & application B253-B255 Order form for non-standard products B534-B535
B 283
ISO Kennzeichen Schnittdaten Graphische Werkzeug- & Anwendungsbeschr. Bestellformular für Sonderwerkzeuge
