Каталог YG-1 инструментальная оснастка - страница 96

D D1 D2 & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic TAPPING ER CHUCK РЕЗЬБОНАРЕЗНЫЕ ПАТРОНЫ С ЦАНГОЙ ER TER ER - GEWINDESCHNEIDFUTTER YG-1 TOOLING SYSTEM MANDRIN DE TARAUDAGE PINCE ER MANDRINI PORTAPINZA ER PER MASCHIATURA PORTAPINZAS ER PARA MACHOS SLEEVE TAPPING CHUCK L1 BODY L TaperJIS B6339AccuracyG ValueRPM CoolantSystem • GEWINDESCHNEID - SCHNELLWECHSELFUTTER ■ JIS B6339/MAS 403-BT - BT AT3 - - A • TARAUDER À CHANGEMENT RAPIDE Unit : mm • MANDRINO PER MASCHIARE TAPER No. MODEL No. EDP No. D D1 D2 L L1 NUT WEIGHT (Kg) BT40-TER16-100 P2774159 28 41 45 100 68.4 ER16 1.45 • PORTAMACHOS DE CAMBIO RAPIDO BT40-TER16-150 P2774160 28 41 45 150 118.4 ER16 2.00 40 BT40-TER32-110 P2774161 50 58 63 110 72 ER32 2.20 BT40-TER32-150 P2774162 50 58 63 150 112 ER32 2.70 BT50-TER16-115 P2774163 28 41 45 115 79.4 ER16 3.95 BT50-TER16-150 P2774164 28 41 45 150 114.4 ER16 4.35 50 BT50-TER32-120 P2774165 50 58 63 120 83 ER32 4.70 BT50-TER32-150 P2774166 50 58 63 150 113 ER32 5.20 DIN 69871-SK ▶ CAT(ANSI B5.50) taper and Inch type products area available. ▶ ER collet of page 95~97, and Tap ER collet of page 98~99 are applicable. DIN 69893/ISO 12164-1-HSK JIS B6339/MAS 403-BT STRAIGHT-K DIN 228-MTA ACCESSORY TAP ADAPTER 186 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 187
