Каталог YG-1 инструментальная оснастка - страница 76

d1 D1 d1 D1 HydraulicShrink FitER ColletEnd Mill HolderShell MillPower MillingMorse TaperSK SlimSynchroTappingTappingFace MillNC Drill ChuckBoringAccessory ChuckHolderChuck& Side Lock ArborArborChuckArborChuckTapping ChuckER ChuckChuckArbor& Other Tool HoldersSystem& Others & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic POWER MILLING CHUCK POWER MILLING CHUCK ВЫСОКОСКОРОСТНЫЕ ФРЕЗЕРНЫЕ ПАТРОНЫ C ФРЕЗЕРНЫЕ ПАТРОНЫ C HOCHGESCHWINDIGKEITS FRÄSERFUTTER FRÄSERSPANNFUTTER MANDRIN PORTE FRAISE À GRANDE VITESSE MANDRIN PORTE FRAISE MANDRINI PORTA FRESA PER ALTA VELOCITÀ MANDRINI PORTA FRESA PORTAHERRAMIENTAS PARA FRESADO DE ALTA VELOCIDAD PORTAHERRAMIENTAS PARA FRESADO H H TAPER No. TAPER No. L L TaperJIS B6339AccuracyG ValueRPM CoolantSystem TaperJIS B6339AccuracyG ValueRPM CoolantSystem ■ JIS B6339/MAS 403-BT - BT AT3 6.3 20,000 AD ■ JIS B6339/MAS 403-BT - BT AT3 - - AD Unit : mm Unit : mm TAPER No. MODEL No. EDP No. d1 D1 L H WEIGHT (Kg) TAPER No. MODEL No. EDP No. d1 D1 L H WEIGHT (Kg) BT30-C20-75HS P2546101 20 54 75 70 1.50 BT30-C20-75 P2546001 20 54 75 70 1.50 30 30 BT30-C25-80HS P2546102 25 62.5 80 70 2.00 BT30-C25-80 P2546002 25 62.5 80 70 2.00 BT40-C20-80HS P2546103 20 54 80 70 2.00 BT40-C20-80 P2546003 20 54 80 70 2.00 BT40-C20-105HS P2546104 20 54 105 70 2.10 BT40-C20-105 P2546004 20 54 105 70 2.10 BT40-C25-105HS P2546105 25 62.5 105 80 2.50 BT40-C25-105 P2546005 25 62.5 105 80 2.50 40 40 BT40-C32-90HS P2546106 32 74 90 100 3.00 BT40-C32-90 P2546006 32 72 90 100 3.00 BT40-C32-105HS P2546107 32 74 105 100 3.10 BT40-C32-105 P2546007 32 72 105 100 3.10 BT40-C32-135HS P2546108 32 74 135 100 3.30 BT40-C32-135 P2546008 32 72 135 100 3.30 BT50-C20-105HS P2546109 20 54 105 70 4.50 BT50-C20-105 P2546009 20 54 105 70 4.50 BT50-C20-135HS P2546110 20 54 135 70 4.90 BT50-C20-135 P2546010 20 54 135 70 4.90 BT50-C20-165HS P2546111 20 54 165 70 5.40 BT50-C20-165 P2546011 20 54 165 70 5.40 BT50-C25-105HS P2546112 25 62.5 105 80 5.20 BT50-C25-105 P2546012 25 62.5 105 80 5.20 BT50-C25-135HS P2546113 25 62.5 135 80 5.80 BT50-C25-135 P2546013 25 62.5 135 80 5.80 BT50-C25-165HS P2546114 25 62.5 165 80 6.20 BT50-C25-165 P2546014 25 62.5 165 80 6.20 50 BT50-C32-105HS P2546115 32 74 105 100 6.00 50 BT50-C32-105 P2546015 32 72 105 100 6.00 BT50-C32-135HS P2546116 32 74 135 100 6.70 BT50-C32-115 P2546016 32 72 115 100 6.20 BT50-C32-165HS P2546117 32 74 165 100 7.40 BT50-C32-135 P2546017 32 72 135 100 6.70 BT50-C42-115HS P2546118 42 92 115 110 6.70 BT50-C32-165 P2546018 32 72 165 100 7.40 BT50-C42-135HS P2546119 42 92 135 110 7.60 BT50-C42-115 P2546019 42 92 115 110 6.70 BT50-C42-165HS P2546120 42 92 165 110 8.30 BT50-C42-135 P2546020 42 92 135 110 7.60 ▶ CAT(ANSI B5.50) taper and Inch type products are available. BT50-C42-165 P2546121 42 92 165 110 8.30 ▶ For applicable collet and spanner, please refer to page 154. ▶ CAT(ANSI B5.50) taper and Inch type products are available. ▶ For applicable collet and spanner, please refer to page 154. 146 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 147
