Каталог YG-1 инструментальная оснастка - страница 126

DC CD ABBA & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic BORING SYSTEM ВСТАВНЫЕ РЕЗЦЫ PART YG-1 TOOLING SYSTEM 45˚ E ACCESSORY & OTHERS Unit : mm SIZE CLASSIFICATION EDP No. A B C D E SCREW WRENCH INSERT SBC08-45 P2775456 08 08 6.3 8.39 70 SSB-2506 T7 CCMT0602 SBC10-45 P2775457 10 10 7 10.39 70 SSB-2506 T7 CCMT0602 SBC13-45 P2775458 13 13 10 13.6 80 SSB-4009 T15 CCMT09T3 SBC16-45 P2775459 16 16 11 16.68 100 SSB-5012 T15 CCMT1204 SBC19-45 P2775460 19 19 11 19.68 100 SSB-5012 T15 CCMT1204 SBC25-45 P2775461 25 25 12.5 25.68 120 SSB-5012 T15 CCMT1204 PULL STUD BOLT PULL STUD BOLT & SPANNER E TOOL CLAMP HEIGHT PRESETTER Unit : mm COOLANT TUBE SIZE CLASSIFICATION EDP No. A B C D E SCREW WRENCH INSERT TECHNICAL DATA : SHANK STANDARD SBC08-90 P2775462 08 08 6.3 8.4 70 SSB-2506 T7 CCMT0602 DIN 69871-SK / JIS B6339/MAS 403-BT / DIN 69893/ISO 12164-1-HSK SBC10-90 P2775463 10 10 7 10.4 70 SSB-2506 T7 CCMT0602 SBC13-90 P2775464 13 13 10 13.6 80 SSB-4009 T15 CCMT09T3 ANSI/ASME B5.50-CAT SBC16-90 P2775465 16 16 11 16.7 100 SSB-5012 T15 CCMT1204 DIN 228 (MORSE TAPER) : TANG / SCREW TYPE SBC19-90 P2775466 19 19 11 19.7 100 SSB-5012 T15 CCMT1204 SBC25-90 P2775467 25 25 12.5 25.7 120 SSB-5012 T15 CCMT1204 246 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 247
