Каталог YG-1 инструментальная оснастка - страница 107

D HydraulicShrink FitER ColletEnd Mill HolderShell MillPower MillingMorse TaperSK SlimSynchroTappingTappingFace MillNC Drill ChuckBoringAccessory ChuckHolderChuck& Side Lock ArborArborChuckArborChuckTapping ChuckER ChuckChuckArbor& Other Tool HoldersSystem& Others NC DRILL CHUCK NC DRILL CHUCK & OTHER TOOL HOLDERS СВЕРЛИЛЬНЫЕ ПАТРОНЫ ДЛЯ СТАНКОВ С ЧПУ NPU NC - BOHRFUTTER MANDRIN DE PERÇAGE NC NC MANDRINI PORTA PUNTE PORTABROCAS PARA BROCAS NC L L1 CBT TaperAccuracyG Value RPM CoolantSystem ■ CBT (BT DUAL CONTACT) AT3 - - A Unit : mm TAPER No. MODEL No. EDP No. CLAMPING RANGE D L (Min.) L1 (Max.) WEIGHT (Kg) CBT30-NPU8-75 P2776066 0.3 - 8 36.5 75 80.7 0.80 30 CBT30-NPU13-105 P2776067 1 - 13 50.4 105 115 1.80 FEATURE Strong Chucking Power CBT40-NPU8-80 P2776068 0.3 - 8 36.5 80 85.7 1.50 CBT40-NPU8-110 P2776054 0.3 - 8 36.5 110 115.7 1.80 YG-1 Drill Chuck is completely tightened with solid bolt, and Drill may be damaged due to reverse thrust during perforation, CBT40-NPU8-150 P2776055 0.3 - 8 36.5 150 155.7 2.60 there is no danger of falling during rotating or cutting. but with YG-1 Drill Chuck strongly tightened with wrench, there 40 CBT40-NPU13-95 P2776069 1 - 13 50.4 95 100.7 2.10 is no possibility of damage to drill. CBT40-NPU13-130 P2776057 1 - 13 50.4 130 140 2.70 CBT40-NPU13-150 P2776058 1 - 13 50.4 150 160 3.40 CBT50-NPU8-90 P2776059 0.3 - 8 36.5 90 95.7 4.20 CBT50-NPU8-110 P2776060 0.3 - 8 36.5 110 115.7 4.50 CBT50-NPU8-170 P2776061 0.3 - 8 36.5 170 180.7 5.20 HIGH PRECISION Safety 50 CBT50-NPU13-105 P2776070 1 - 13 50.4 105 115 4.80 YG-1 NC Drill Chuck with strong rigidity contributes to factory CBT50-NPU13-130 P2776063 1 - 13 50.4 130 140 5.20 CBT50-NPU13-150 P2776064 1 - 13 50.4 150 160 5.50 automation by unmanned operation by preventing accident CBT50-NPU13-190 P2776065 1 - 13 50.4 190 200 5.90 from occuring during operation. ▶ SK(DIN 69871) and CAT(ANSI B5.50) taper products available. - Falling of drill occurring by sudden stopping - Falling of drill occurring by rapid rotation - ‌D amage to drill caused by reverse thrust during perforation process • ‌Drill chuck with excellent high precision (T.I.R 0.05) and shank are integrated, which guarantees excellent T.I.R 208 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 209
