GG DD C C GG DD CC HydraulicShrink FitER ColletEnd Mill HolderShell MillPower MillingMorse TaperSK SlimSynchroTappingTappingFace MillNC Drill ChuckBoringAccessory ChuckHolderChuck& Side Lock ArborArborChuckArborChuckTapping ChuckER ChuckChuckArbor& Other Tool HoldersSystem& Others & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic FACE MILL ARBOR FACE MILL ARBOR ОПРАВКИ ДЛЯ ТОРЦОВЫХ ФРЕЗ FMC ОПРАВКИ ДЛЯ ТОРЦОВЫХ ФРЕЗ FMC AUFNAHMEDORN FÜR MESSERKÖPFE AUFNAHMEDORN FÜR MESSERKÖPFE ARBRE PORTE FRAISE À ALÉSAGE FIG.1 L HMANDRINO PORTA FRESE FRONTALEK ARBRE PORTE FRAISE À ALÉSAGE FIG.1 L HKMANDRINO PORTA FRESE FRONTALE EJE PARA PLATOS DE PLACAS EJE PARA PLATOS DE PLACAS W W L H L H FIG.2 K FIG.2 K W W 15 15 CBT TaperAccuracy G Value RPM CoolantSystem■ CBT (BT DUAL CONTACT)AT32.525,000A■ JIS B6339/MAS 403-BT TaperJIS B6339AccuracyG Value RPM CoolantSystem- BTAT36.315,000A ◆ METRIC TYPE Unit : mm ◆ METRIC TYPE Unit : mm TAPER No. MODEL No. EDP No. D L C H W K G FIG. WEIGHT (Kg) TAPER No. MODEL No. EDP No. D L C H W K G FIG. WEIGHT (Kg) 30 CBT30-FMC22-45 P2776131 22 45 45 18 10 5 M10 2 0.80 30 BT30-FMC22-45 P2776101 22 45 45 18 10 5 M10 2 0.80 CBT40-FMC22-45 P2776132 22 45 45 18 10 5 M10 1 1.30 BT40-FMC22-45 P2776102 22 45 45 18 10 5 M10 1 1.30 40 CBT40-FMC27-60 P2776133 27 60 70 20 12 6 M12 2 1.50 40 BT40-FMC27-60 P2776103 27 60 70 20 12 6 M12 2 1.50 CBT40-FMC32-60 P2776134 32 60 85 22 14 7 M16 2 2.30 BT40-FMC32-60 P2776104 32 60 85 22 14 7 M16 2 2.30 CBT50-FMC22-60 P2776135 22 60 45 18 10 5 M10 1 4.20 BT50-FMC22-60 P2776105 22 60 45 18 10 5 M10 1 4.20 CBT50-FMC22-105 P2776136 22 105 45 18 10 5 M10 1 4.70 BT50-FMC22-105 P2776106 22 105 45 18 10 5 M10 1 4.70 CBT50-FMC22-150 P2776137 22 150 45 18 10 5 M10 1 5.30 BT50-FMC22-150 P2776107 22 150 45 18 10 5 M10 1 5.30 CBT50-FMC27-45 P2776138 27 45 70 20 12 6 M12 1 4.10 BT50-FMC27-45 P2776108 27 45 70 20 12 6 M12 1 4.10 50 CBT50-FMC27-90 P2776139 27 90 70 20 12 6 M12 1 5.50 50 BT50-FMC27-90 P2776109 27 90 70 20 12 6 M12 1 5.50 CBT50-FMC27-150 P2776140 27 150 70 20 12 6 M12 1 7.30 BT50-FMC27-150 P2776110 27 150 70 20 12 6 M12 1 7.30 CBT50-FMC32-60 P2776141 32 60 85 22 14 7 M16 1 4.20 BT50-FMC32-60 P2776111 32 60 85 22 14 7 M16 1 4.20 CBT50-FMC32-105 P2776142 32 105 85 22 14 7 M16 1 5.50 BT50-FMC32-105 P2776112 32 105 85 22 14 7 M16 1 5.50 CBT50-FMC32-150 P2776143 32 150 85 22 14 7 M16 1 7.00 BT50-FMC32-150 P2776113 32 150 85 22 14 7 M16 1 7.00 ◆ INCH TYPE Unit : mm ◆ INCH TYPE Unit : mm TAPER No. MODEL No. EDP No. D L C H W K G FIG. WEIGHT (Kg) TAPER No. MODEL No. EDP No. D L C H W K G FIG. WEIGHT (Kg) 30 CBT30-FMC25.4-45 P2776144 25.4 45 70 20 9.5 6 M12 2 1.10 30 BT30-FMC25.4-45 P2776114 25.4 45 70 20 9.5 6 M12 2 1.10 CBT40-FMC25.4-60 P2776145 25.4 60 70 20 9.5 6 M12 2 1.50 BT40-FMC25.4-60 P2776115 25.4 60 70 20 9.5 6 M12 2 1.50 CBT40-FMC25.4-90 P2776146 25.4 90 70 20 9.5 6 M12 2 2.20 BT40-FMC25.4-90 P2776116 25.4 90 70 20 9.5 6 M12 2 2.20 40 40 CBT40-FMC38.1-60 P2776147 38.1 60 85 22 15.9 7 M16 2 2.30 BT40-FMC38.1-60 P2776117 38.1 60 85 22 15.9 7 M16 2 2.30 CBT40-FMC38.1-75 P2776148 38.1 75 85 22 15.9 7 M16 2 2.60 BT40-FMC38.1-75 P2776118 38.1 75 85 22 15.9 7 M16 2 2.60 CBT50-FMC25.4-45 P2776149 25.4 45 70 20 9.5 6 M12 1 4.10 BT50-FMC25.4-45 P2776119 25.4 45 70 20 9.5 6 M12 1 4.10 CBT50-FMC25.4-90 P2776150 25.4 90 70 20 9.5 6 M12 1 5.50 BT50-FMC25.4-90 P2776120 25.4 90 70 20 9.5 6 M12 1 5.50 CBT50-FMC25.4-150 P2776151 25.4 150 70 20 9.5 6 M12 1 7.30 BT50-FMC25.4-150 P2776121 25.4 150 70 20 9.5 6 M12 1 7.30 50 50 CBT50-FMC38.1-45 P2776152 38.1 45 85 22 15.9 7 M16 1 4.20 BT50-FMC38.1-45 P2776122 38.1 45 85 22 15.9 7 M16 1 4.20 CBT50-FMC38.1-75 P2776153 38.1 75 85 22 15.9 7 M16 1 5.50 BT50-FMC38.1-75 P2776123 38.1 75 85 22 15.9 7 M16 1 5.50 CBT50-FMC38.1-105 P2776154 38.1 105 85 22 15.9 7 M16 1 7.00 BT50-FMC38.1-105 P2776124 38.1 105 85 22 15.9 7 M16 1 7.00 ▶ Through coolant system is optional. ▶ Through coolant system is optional. ▶ For parts, please refer to page 207. ▶ CAT(ANSI B5.50) taper and Inch type products are available. ▶ For parts, please refer to page 207. 202 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 203
