Каталог YG-1 инструментальная оснастка - страница 100

D D2 W & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic TAPPING CHUCK ПЕРЕХОДНИКИ ДЛЯ МЕТЧИКОВ (DIN) TC SCHNELLWECHSEL-EINSATZ YG-1 TOOLING SYSTEM ADAPTATEUR CHANGEMENT RAPIDE BUSSOLA A INNESTO RAPIDO INSERTO DE CAMBIO RAPIDO L FACE MILL D1 ARBOR W H • AUFNAHMEDORN FÜR MESSERKÖPFE ■ Below standard Tap Adapter conforms to DIN. • ARBRE PORTE FRAISE À ALÉSAGE Unit : mm • MANDRINO PORTA FRESE FRONTALE TAPER No. MODEL No. EDP No. D D1 (Ø) D2 H W (□) L DIN No. WEIGHT (Kg) TCS12D-2821 P2774601 32 2.8 19 25 2.1 24 371 0.20 • EJE PARA PLATOS DE PLACAS TCS12D-3527 P2774602 32 3.5 19 25 2.7 24 371 0.20 TCS12D-4534 P2774603 32 4.5 19 25 3.4 24 371 0.20 TCS12D-43 P2774604 32 4 19 25 3 24 371 0.20 TCS12D-5543 P2774605 32 5.5 19 25 4.3 25 376 0.20 TSC12D TCS12D-649 P2774606 32 6 19 25 4.9 25 371 0.20 TCS12D-755 P2774607 32 7 19 25 5.5 25 376 0.20 TCS12D-862 P2774608 32 8 19 25 6.2 25 371 0.20 CBT (BT DUAL CONTACT) TCS12D-97 P2774609 32 9 19 25 7 26 376 0.20 FMA TCS12D-108 P2774610 32 10 19 25 8 26 371 0.20 TCS12D-119 P2774611 32 11 19 25 9 26 376 0.20 JIS B6339/MAS 403-BT TCS24D-649 P2774612 52 6 31 33 4.9 38 371 0.60 FMA TCS24D-755 P2774613 52 7 31 33 5.5 38 376 0.60 TCS24D-862 P2774614 52 8 31 33 6.2 38 371 0.60 DIN 69893/ISO 12164-1-HSK TCS24D-97 P2774615 52 9 31 33 7 38 376 0.60 FMA TCS24D-108 P2774616 52 10 31 33 8 39 371 0.60 TCS24D TCS24D-119 P2774617 52 11 31 33 9 41 376 0.60 ANSI B5.18-NT TCS24D-129 P2774618 52 12 31 33 9 43 376 0.60 FMA TCS24D-1411 P2774619 52 14 31 33 11 43 376 0.60 TCS24D-1612 P2774620 52 16 31 33 12 46 376 0.60 DIN 228-MTA TCS24D-18145 P2774621 52 18 31 33 14.5 46 376 0.60 TCS38D-119 P2774622 72 11 48 45 9 43 376 1.80 CBT (BT DUAL CONTACT) TCS38D-129 P2774623 72 12 48 45 9 43 376 1.80 TCS38D-1411 P2774624 72 14 48 45 11 45 376 1.80 FMB / FMC TCS38D-1612 P2774625 72 16 48 45 12 45 376 1.80TCS38DTCS38D-18145P27746267218484514.5623761.80 JIS B6339/MAS 403-BT TCS38D-2016 P2774627 72 20 48 45 16 64 376 1.80 FMB / FMC TCS38D-2218 P2774628 72 22 48 45 18 66 376 1.80 TCS38D-2520 P2774629 72 25 48 45 20 68 376 1.80 DIN 69893/ISO 12164-1-HSK TCS38D-2822 P2774630 72 28 48 45 22 68 376 1.80 FMC ▶ Feature : Quick Change Type with Built-in Torque Safety Device ▶ For Pipe Type Tap, please discuss separately. 194 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 195
