| UNC | SP | SL | PO | ST | ROLL | CARBIDE | LONG | HAND TAPS | EG (STI) | SPECIAL THREADS, GAUGES | Dies |
| No.1-64UNC | J | J -A | J -A | D | |||||||
| No.2-56UNC | J -A | A | J -A | J -A | J -A | D | |||||
| No.3-48UNC | J -A | J -A | J -A | J -A | D | ||||||
| No.4-40UNC | D -J -A | A | D -J -A | J -A | J -A | J | D | ||||
| No.5-40UNC | D -J -A | A | D -J -A | J -A | J -A | J | D | ||||
| No.6-32UNC | D -J -A | A | D -J -A | J -A | J -A | J | D | ||||
| No.8-32UNC | D -J -A | A | D -J -A | J -A | J -A | J | D | ||||
| No.10-24UNC | D -J -A | A | D -J -A | J -A | J -A | J | D | ||||
| No.12-24UNC | D -J -A | D -J -A | J -A | J | D | ||||||
| 1/4-20UNC | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 5/16-18UNC | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 3/8-16UNC | D -J -A | A | D -J -A | D -J -A | A | J | J | D | |||
| 7/16-14UNC | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 1/2-13UNC | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 9/16-12UNC | D -J -A | D -J -A | D -J -A | D | |||||||
| 5/8-11UNC | D -J -A | A | D -J -A | D -J -A | J | J | D | ||||
| 3/4-10UNC | D -J -A | A | D -J -A | D -J -A | J | J | D | ||||
| 7/8-9UNC | D -J -A | D -J -A | D -J -A | J | D | ||||||
| 1 -8UNC | D -J -A | D -J -A | D -J -A | J | D | ||||||
| 1 1/8-7UNC | D -J -A | D -J -A | J -A | ||||||||
| 1 1/4-7UNC | D -J -A | D -J -A | J -A | ||||||||
| 1 3/8-6UNC | D -J -A | D -J -A | J -A | ||||||||
| 1 1/2-6UNC | D -J -A | D -J -A | J -A | ||||||||
| 1 3/4-5UNC | D -J -A | D -A | J | ||||||||
| 2 -4.5UNC | D -J -A | A | J | ||||||||
| UNF | |||||||||||
| SP | SL | PO | ST | ROLL | CARBIDE | LONG | HAND TAPS | EG (STI) | SPECIAL THREADS, GAUGES | Dies | |
| No.0-80UNF | J -A | J -A | J -A | D | |||||||
| No.1-72UNF | J -A | J -A | J | D | |||||||
| No.2-64UNF | J -A | J -A | J -A | J | D | ||||||
| No.3-56UNF | J -A | J -A | J -A | J -A | D | ||||||
| No.4-48UNF | D -J -A | D -J -A | J -A | J -A | J | D | |||||
| No.5-44UNF | D -J -A | D -J -A | J -A | J | D | ||||||
| No.6-40UNF | D -J -A | D -J -A | J -A | J | D | ||||||
| No.8-36UNF | D -J -A | D -J -A | J -A | J | D | ||||||
| No.10-32UNF | D -J -A | A | D -J -A | J -A | J -A | J | D | ||||
| No.12-28UNF | D -J -A | D -J -A | J -A | J | D | ||||||
| 1/4-28UNF | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 5/16-24UNF | D -J -A | A | D -J -A | D -J -A | A | J | J | D | |||
| 3/8-24UNF | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 7/16-20UNF | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 1/2-20UNF | D -J -A | A | D -J -A | D -J -A | J -A | J | J | D | |||
| 9/16-18UNF | D -J -A | D -J -A | D -J -A | J | D | ||||||
| 5/8-18UNF | D -J -A | A | D -J -A | D -J -A | J | J | D | ||||
| 3/4-16UNF | D -J -A | A | D -J -A | D -J -A | J | J | D | ||||
| 7/8-14UNF | D -J -A | D -J -A | D -J -A | J | D | ||||||
| 1 -12UNF | D -J -A | D -J -A | D -J -A | J | D | ||||||
| 1 1/8-12UNF | D -J -A | D -J -A | J -A | ||||||||
| 1 1/4-12UNF | D -J -A | D -J -A | J -A | ||||||||
| 1 3/8-12UNF | D -J -A | D -J -A | J -A | ||||||||
| 1 1/2-12UNF | D -J -A | D -J -A | J -A |
