| M-MF | Code | LF ( mm ) | L ( mm ) | D1 (Thread engagement ratio) | D2 (Thread engagement ratio) | DCON ( mm ) | L1 ( mm ) | L2 ( mm ) | L3 ( mm ) | Type | Stock | Intro |
| YMW | ||||||||||||
| CPCS010NA | 110 | 27.5 | 8.647 (100%) | 8.782 (90%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010NB | 110 | 27.5 | 8.714 (95%) | 8.850 (85%) | 10 | 15 | 20 | 25 | 01 | f | SP | |
| CPCS010NC | 110 | 27.5 | 8.782 (90%) | 8.917 (80%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010ND | 110 | 27.5 | 8.850 (85%) | 8.985 (75%) | 10 | 15 | 20 | 25 | 01 | f | ||
| M10X1.25 | CPCS010NE | 110 | 27.5 | 8.917 (80%) | 9.053 (70%) | 10 | 15 | 20 | 25 | 01 | f | |
| CPCS010NF | 110 | 27.5 | 8.985 (75%) | 9.120 (65%) | 10 | 15 | 20 | 25 | 01 | f | SL | |
| CPCS010NM | set of 5pcs. C | PCS010NB (95 | %) ~ CPC | S010NF (65%) | 01 | f | ||||||
| CPCS010NS | set of 5pcs. C | PCS010NA (10 | 0%) ~ CPC | S010NE (70%) | 01 | f | ||||||
| CPCS010MA | 110 | 27.5 | 8.917 (100%) | 9.026 (90%) | 10 | 15 | 20 | 25 | 01 | f | PO | |
| CPCS010MB | 110 | 27.5 | 8.972 (95%) | 9.080 (85%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010MC | 110 | 27.5 | 9.026 (90%) | 9.134 (80%) | 10 | 15 | 20 | 25 | 01 | f | ||
| M10X1 | CPCS010MD | 110 | 27.5 | 9.080 (85%) | 9.188 (75%) | 10 | 15 | 20 | 25 | 01 | f | |
| CPCS010ME | 110 | 27.5 | 9.134 (80%) | 9.242 (70%) | 10 | 15 | 20 | 25 | 01 | f | ST | |
| CPCS010MF | 110 | 27.5 | 9.188 (75%) | 9.296 (65%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010MM | set of 5pcs. C | PCS010MB (95 | %) ~ CPC | S010MF (65%) | 01 | f | ||||||
| CPCS010MS | set of 5pcs. CP | CS010MA (10 | 0%) ~ CPC | S010ME (70%) | 01 | f | ||||||
| CPCS010JA | 110 | 27.5 | 9.188 (100%) | 9.269 (90%) | 10 | 15 | 20 | 25 | 01 | f | ROLL | |
| CPCS010JB | 110 | 27.5 | 9.229 (95%) | 9.310 (85%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010JC | 110 | 27.5 | 9.269 (90%) | 9.350 (80%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010JD | 110 | 27.5 | 9.310 (85%) | 9.391 (75%) | 10 | 15 | 20 | 25 | 01 | f | CARBIDE | |
| M10X0.75 | CPCS010JE | 110 | 27.5 | 9.350 (80%) | 9.432 (70%) | 10 | 15 | 20 | 25 | 01 | f | |
| CPCS010JF | 110 | 27.5 | 9.391 (75%) | 9.472 (65%) | 10 | 15 | 20 | 25 | 01 | f | ||
| CPCS010JM | set of 5pcs. C | PCS010JB (95 | %) ~ CPC | S010JF (65%) | 01 | f | ||||||
| LONG | ||||||||||||
| CPCS010JS | set of 5pcs. C | CS010JA (10 | %) ~ CP | S010JE (70%) | 01 | f | ||||||
| CPCS011OA | 121 | 33 | 9.376 (100%) | 9.538 (90%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| CPCS011OB | 121 | 33 | 9.457 (95%) | 9.620 (85%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| CPCS011OC | 121 | 33 | 9.538 (90%) | 9.701 (80%) | 12 | 16.5 | 22 | 27.5 | 01 | f | HAND | |
| CPCS011OD | 121 | 33 | 9.620 (85%) | 9.782 (75%) | 12 | 16.5 | 22 | 27.5 | 01 | f | TAPS | |
| M11X1.5 | CPCS011OE | 121 | 33 | 9.701 (80%) | 9.863 (70%) | 12 | 16.5 | 22 | 27.5 | 01 | f | |
| CPCS011OF | 121 | 33 | 9.782 (75%) | 9.944 (65%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| CPCS011OM | set of 5pcs. C | PCS011OB (95 | %) ~ CPC | S011OF (65%) | 01 | f | EG (STI) | |||||
| CPCS011OS | set of 5pcs. C | PCS011OA (10 | 0%) ~ CPC | S011OE (70%) | 01 | f | ||||||
| CPCS011MA | 121 | 33 | 9.917 (100%) | 10.026 (90%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| CPCS011MB | 121 | 33 | 9.972 (95%) | 10.080 (85%) | 12 | 16.5 | 22 | 27.5 | 01 | f | SPECIAL | |
| CPCS011MC | 121 | 33 | 10.026 (90%) | 10.134 (80%) | 12 | 16.5 | 22 | 27.5 | 01 | f | THREADS, GAUGES | |
| CPCS011MD | 121 | 33 | 10.080 (85%) | 10.188 (75%) | 12 | 16.5 | 22 | 27.5 | 01 | f | YMW | |
| M11X1 | CPCS011ME | 121 | 33 | 10.134 (80%) | 10.242 (70%) | 12 | 16.5 | 22 | 27.5 | 01 | f | |
| CPCS011MF | 121 | 33 | 10.188 (75%) | 10.296 (65%) | 12 | 16.5 | 22 | 27.5 | 01 | f | THREAD | |
| CPCS011MM | set of 5pcs. C | PCS011MB (95 | %) ~ CPC | S011MF (65%) | 01 | f | MILLS | |||||
| CPCS011MS | set of 5pcs. CP | CS011MA (10 | 0%) ~ CPC | S011ME (70%) | 01 | f | ||||||
| CPCS011JA | 121 | 33 | 10.188 (100%) | 10.269 (90%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| CPCS011JB | 121 | 33 | 10.229 (95%) | 10.310 (85%) | 12 | 16.5 | 22 | 27.5 | 01 | f | DIES | |
| CPCS011JC | 121 | 33 | 10.269 (90%) | 10.350 (80%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| CPCS011JD | 121 | 33 | 10.310 (85%) | 10.391 (75%) | 12 | 16.5 | 22 | 27.5 | 01 | f | ||
| M11X0.75 | CPCS011JE | 121 | 33 | 10.350 (80%) | 10.432 (70%) | 12 | 16.5 | 22 | 27.5 | 01 | f | CENTER |
| CPCS011JF | 121 | 33 | 10.391 (75%) | 10.472 (65%) | 12 | 16.5 | 22 | 27.5 | 01 | f | DRILLS | |
| CPCS011JM | set of 5pcs. C | PCS011JB (95 | %) ~ CPC | S011JF (65%) | 01 | f | ||||||
| CPCS011JS | set of 5pcs. C | PCS011JA (10 | 0%) ~ CPC | S011JE (70%) | 01 | f |
