| M-MF | Code | LF ( mm ) | L ( mm ) | D1 (Thread engagement ratio) | D2 (Thread engagement ratio) | DCON ( mm ) | L1 ( mm ) | L2 ( mm ) | L3 ( mm ) | Type | Stock | Intro |
| YMW | ||||||||||||
| CPCS2.0EA | 41.5 | 5.5 | 1.567 (100%) | 1.610 (90%) | 3 | 3 | 4 | 5 | 01 | f | ||
| CPCS2.0EB | 41.5 | 5.5 | 1.589 (95%) | 1.632 (85%) | 3 | 3 | 4 | 5 | 01 | f | SP | |
| CPCS2.0EC | 41.5 | 5.5 | 1.610 (90%) | 1.654 (80%) | 3 | 3 | 4 | 5 | 01 | f | ||
| M2X04 | CPCS2.0ED | 41.5 | 5.5 | 1.632 (85%) | 1.675 (75%) | 3 | 3 | 4 | 5 | 01 | f | |
| . | CPCS2.0EE | 41.5 | 5.5 | 1.654 (80%) | 1.697 (70%) | 3 | 3 | 4 | 5 | 01 | f | |
| CPCS2.0EF | 41.5 | 5.5 | 1.675 (75%) | 1.719 (65%) | 3 | 3 | 4 | 5 | 01 | f | SL | |
| CPCS2.0EM | set of 5pcs. | CPCS2.0EB (95 | %) ~ CPC | S2.0EF (65%) | 01 | f | ||||||
| CPCS2.0ES | set of 5pcs. C | PCS2.0EA (10 | 0%) ~ CPC | S2.0EE (70%) | 01 | f | ||||||
| CPCS2.5FA | 45 | 7.5 | 2.013 (100%) | 2.062 (90%) | 3 | 3.75 | 5 | 6.25 | 01 | f | PO | |
| CPCS2.5FB | 45 | 7.5 | 2.037 (95%) | 2.086 (85%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| CPCS2.5FC | 45 | 7.5 | 2.062 (90%) | 2.110 (80%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| M25X045 | CPCS2.5FD | 45 | 7.5 | 2.086 (85%) | 2.135 (75%) | 3 | 3.75 | 5 | 6.25 | 01 | f | |
| .. | CPCS2.5FE | 45 | 7.5 | 2.110 (80%) | 2.159 (70%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ST |
| CPCS2.5FF | 45 | 7.5 | 2.135 (75%) | 2.183 (65%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| CPCS2.5FM | set of 5pcs. | CPCS2.5FB (95 | %) ~ CPC | S2.5FF (65%) | 01 | f | ||||||
| CPCS2.5FS | set of 5pcs. C | PCS2.5FA (10 | 0%) ~ CPC | S2.5FE (70%) | 01 | f | ROLL | |||||
| CPCS2.5DA | 45 | 7.5 | 2.121 (100%) | 2.159 (90%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| CPCS2.5DB | 45 | 7.5 | 2.140 (95%) | 2.178 (85%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| CPCS2.5DC | 45 | 7.5 | 2.159 (90%) | 2.197 (80%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| CPCS2.5DD | 45 | 7.5 | 2.178 (85%) | 2.216 (75%) | 3 | 3.75 | 5 | 6.25 | 01 | f | CARBIDE | |
| M2.5X0.35 | CPCS2.5DE | 45 | 7.5 | 2.197 (80%) | 2.235 (70%) | 3 | 3.75 | 5 | 6.25 | 01 | f | |
| CPCS2.5DF | 45 | 7.5 | 2.216 (75%) | 2.254 (65%) | 3 | 3.75 | 5 | 6.25 | 01 | f | ||
| CPCS2.5DM | set of 5pcs. | CPCS2.5DB (95 | %) ~ CPC | S2.5DF (65%) | 01 | f | ||||||
| CPCS2.5DS | set of 5pcs. C | PCS2.5DA (10 | 0%) ~ CPC | S2.5DE (70%) | 01 | f | LONG | |||||
| CPCS3.0GA | 49 | 9 | 2.459 (100%) | 2.513 (90%) | 4 | 4.5 | 6 | 7.5 | 01 | f | ||
| CPCS3.0GB | 49 | 9 | 2.486 (95%) | 2.540 (85%) | 4 | 4.5 | 6 | 7.5 | 01 | f | ||
| CPCS3.0GC | 49 | 9 | 2.513 (90%) | 2.567 (80%) | 4 | 4.5 | 6 | 7.5 | 01 | f | HAND | |
| MX | CPCS3.0GD | 49 | 9 | 2.540 (85%) | 2.594 (75%) | 4 | 4.5 | 6 | 7.5 | 01 | f | TAPS |
| 30.5 | CPCS3.0GE | 49 | 9 | 2.567 (80%) | 2.621 (70%) | 4 | 4.5 | 6 | 7.5 | 01 | f | |
| CPCS3.0GF | 49 | 9 | 2.594 (75%) | 2.648 (65%) | 4 | 4.5 | 6 | 7.5 | 01 | f | ||
| CPCS3.0GM | set of 5pcs. | CPCS3.0GB (95 | %) ~ CPC | S3.0GF (65%) | 01 | f | EG (STI) | |||||
| CPCS3.0GS | set of 5pcs. C | PCS3.0GA (10 | 0%) ~ CPC | S3.0GE (70%) | 01 | f | ||||||
| CPCS3.0DA | 49 | 9 | 2.621 (100%) | 2.659 (90%) | 4 | 4.5 | 6 | 7.5 | 01 | f | ||
| CPCS3.0DB | 49 | 9 | 2.640 (95%) | 2.678 (85%) | 4 | 4.5 | 6 | 7.5 | 01 | f | SPECIAL THREADS | |
| CPCS3.0DC | 49 | 9 | 2.659 (90%) | 2.697 (80%) | 4 | 4.5 | 6 | 7.5 | 01 | f | , GAUGES | |
| M3X035 | CPCS3.0DD | 49 | 9 | 2.678 (85%) | 2.716 (75%) | 4 | 4.5 | 6 | 7.5 | 01 | f | YMW |
| . | CPCS3.0DE | 49 | 9 | 2.697 (80%) | 2.735 (70%) | 4 | 4.5 | 6 | 7.5 | 01 | f | |
| CPCS3.0DF | 49 | 9 | 2.716 (75%) | 2.754 (65%) | 4 | 4.5 | 6 | 7.5 | 01 | f | THREAD | |
| CPCS3.0DM | set of 5pcs. | CPCS3.0DB (95 | %) ~ CPC | S3.0DF (65%) | 01 | f | MILLS | |||||
| CPCS3.0DS | set of 5pcs. C | PCS3.0DA (10 | 0%) ~ CPC | S3.0DE (70%) | 01 | f | ||||||
| CPCS3.5HA | 57 | 11 | 2.850 (100%) | 2.915 (90%) | 5 | 5.25 | 7 | 8.75 | 01 | f | ||
| CPCS3.5HB | 57 | 11 | 2.883 (95%) | 2.948 (85%) | 5 | 5.25 | 7 | 8.75 | 01 | f | DIES | |
| CPCS3.5HC | 57 | 11 | 2.915 (90%) | 2.980 (80%) | 5 | 5.25 | 7 | 8.75 | 01 | f | ||
| CPCS3.5HD | 57 | 11 | 2.948 (85%) | 3.013 (75%) | 5 | 5.25 | 7 | 8.75 | 01 | f | ||
| M3.5X0.6 | CPCS3.5HE | 57 | 11 | 2.980 (80%) | 3.045 (70%) | 5 | 5.25 | 7 | 8.75 | 01 | f | CENTER |
| CPCS3.5HF | 57 | 11 | 3.013 (75%) | 3.078 (65%) | 5 | 5.25 | 7 | 8.75 | 01 | f | DRILLS | |
| CPCS3.5HM | set of 5pcs. | CPCS3.5HB (95 | %) ~ CPC | S3.5HF (65%) | 01 | f | ||||||
| CPCS3.5HS | set of 5pcs. C | PCS3.5HA (10 | 0%) ~ CPC | S3.5HE (70%) | 01 | f |
