Каталоги Yamawa твердосплавные метчики для закаленной стали
| UNC-UNF YMW | TCTR (tolerance) | Code | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | Type | Stock | Intro |
| N8-32UNC | 2B | ITM2UN8JG | 60 | 9 | 22 | 31 | 5.5 | 4.5 | 7 | 01 | f | |
| o. | 2B | ITM2UN8JN | 60 | 5 | 22 | 31 | 5.5 | 4.5 | 7 | 02 | f | SP |
| No8-36UNF | 2B | ITM2UN8IG | 60 | 9 | 22 | 31 | 5.5 | 4.5 | 7 | 01 | f | |
| . | 2B | ITM2UN8IN | 60 | 5 | 22 | 31 | 5.5 | 4.5 | 7 | 02 | f | |
| 2B | ITM2UNAMG | 60 | 9.5 | 22 | 32 | 5.5 | 4.5 | 7 | 01 | f | ||
| No.10-24UNC | 2B | ITM2UNAMN | 60 | 5 | 22 | 32 | 5.5 | 4.5 | 7 | 02 | f | SL |
| N12UNF | 2B | ITM2UNAJG | 60 | 9.5 | 22 | 32 | 5.5 | 4.5 | 7 | 01 | f | |
| o.0-3 | 2B | ITM2UNAJN | 60 | 5 | 22 | 32 | 5.5 | 4.5 | 7 | 02 | f | |
| No12-24UNC | 2B | ITM2UNCMG | 62 | 9.5 | 26 | 32 | 6 | 4.5 | 7 | 01 | f | PO |
| . | 2B | ITM2UNCMN | 62 | 5 | 26 | 32 | 6 | 4.5 | 7 | 02 | f | |
| N1228UNF | 2B | ITM2UNCKG | 62 | 9.5 | 26 | 32 | 6 | 4.5 | 7 | 01 | f | |
| o.- | 2B | ITM2UNCKN | 62 | 5 | 26 | 32 | 6 | 4.5 | 7 | 02 | f | |
| 2B | ITM2U04NG | 62 | 15 | 26 | 32 | 6 | 4.5 | 7 | 01 | f | ST | |
| 1/4-20UNC | 2B | ITM2U04NN | 62 | 10 | 26 | 32 | 6 | 4.5 | 7 | 02 | f | |
| 2B | ITM2U04KG | 62 | 12 | 26 | 32 | 6 | 4.5 | 7 | 01 | f | ||
| 1/4-28UNF | 2B | ITM2U04KN | 62 | 7 | 26 | 32 | 6 | 4.5 | 7 | 02 | f | |
| 5/16-18UNC | 2B | ITM2U05OG | 70 | 15 | 34 | 36 | 6.2 | 5 | 8 | 03 | f | ROLL |
| 2B | ITM2U05ON | 70 | 10 | 34 | 36 | 6.2 | 5 | 8 | 04 | f | ||
| 2B | ITM2U05MG | 70 | 15 | 34 | 36 | 6.2 | 5 | 8 | 03 | f | ||
| 5/16-24UNF | 2B | ITM2U05MN | 70 | 7 | 34 | 36 | 6.2 | 5 | 8 | 04 | f | CARBIDE |
| 2B | ITM2U06PG | 75 | 17 | 37 | 38 | 7 | 5.5 | 8 | 03 | f | ||
| 3/8-16UNC | 2B | ITM2U06PN | 75 | 10 | 37 | 38 | 7 | 5.5 | 8 | 04 | f | |
| 3/8-24UNF | 2B | ITM2U06MG | 75 | 17 | 37 | 38 | 7 | 5.5 | 8 | 03 | f | |
| 2B | ITM2U06MN | 75 | 10 | 37 | 38 | 7 | 5.5 | 8 | 04 | f | LONG | |
| 7/1614UNC | 2B | ITM2U07QG | 82 | 17 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | |
| - | 2B | ITM2U07QN | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | |
| 7/1620UNF | 2B | ITM2U07NG | 82 | 17 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | HAND |
| - | 2B | ITM2U07NN | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | TAPS |
| 1/213UNC | 2B | ITM2U08RG | 88 | 17 | 43 | 45 | 10.5 | 8 | 11 | 03 | f | |
| - | 2B | ITM2U08RN | 88 | 13 | 43 | 45 | 10.5 | 8 | 11 | 04 | f | |
| 2B | ITM2U08NG | 88 | 17 | 43 | 45 | 10.5 | 8 | 11 | 03 | f | EG (STI) | |
| 1/2-20UNF | 2B | ITM2U08NN | 88 | 10 | 43 | 45 | 10.5 | 8 | 11 | 04 | f | |
| 9/1612UNC | 2B | ITM2U09SG | 95 | 26 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | |
| - | 2B | ITM2U09SN | 95 | 17 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | SPECIAL |
| 9/1618UNF | 2B | ITM2U09OG | 95 | 20 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | THREADS, GAUGES |
| - | 2B | ITM2U09ON | 95 | 13 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | YMW |
| 2B | ITM2U10UG | 95 | 26 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | ||
| 5/8-11UNC | 2B | ITM2U10UN | 95 | 17 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | THREAD |
| 2B | ITM2U10OG | 95 | 20 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | MILLS | |
| 5/8-18UNF | 2B | ITM2U10ON | 95 | 13 | 47 | 48 | 12.5 | 10 | 13 | 04 | f |
