| M-MF | TCTR (tolerance) | Code | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | Type | Stock | Intro |
| YMW | ||||||||||||
| 6H | ITM6010JG | 75 | 9 | 37 | 38 | 7 | 5.5 | 8 | 03 | f | ||
| M10X0.75 | 6H | ITM6010JN | 75 | 6 | 37 | 38 | 7 | 5.5 | 8 | 04 | f | SP |
| M11X1 | 6H | ITM6011OG | 82 | 19 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | |
| .5 | 6H | ITM6011ON | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | |
| M11X1 | 6H | ITM6011MG | 82 | 12 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | |
| 6H | ITM6011MN | 82 | 6 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | SL | |
| M11X075 | 6H | ITM6011JG | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | |
| . | 6H | ITM6011JN | 82 | 6 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | |
| M12X175 | 6H | ITM6012PG | 82 | 20 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | PO |
| . | 6H | ITM6012PN | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | |
| M12X15 | 6H | ITM6012OG | 82 | 20 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | |
| . | 6H | ITM6012ON | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | |
| M12X125 | 6H | ITM6012NG | 82 | 15 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | ST |
| . | 6H | ITM6012NN | 82 | 10 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | |
| 6H | ITM6012MG | 82 | 12 | 40 | 42 | 8.5 | 6.5 | 9 | 03 | f | ||
| M12X1 | 6H | ITM6012MN | 82 | 6 | 40 | 42 | 8.5 | 6.5 | 9 | 04 | f | ROLL |
| M14X2 | 6H | ITM6014QG | 88 | 20 | 43 | 45 | 10.5 | 8 | 11 | 03 | f | |
| 6H | ITM6014QN | 88 | 12 | 43 | 45 | 10.5 | 8 | 11 | 04 | f | ||
| M14X15 | 6H | ITM6014OG | 88 | 20 | 43 | 45 | 10.5 | 8 | 11 | 03 | f | |
| . | 6H | ITM6014ON | 88 | 12 | 43 | 45 | 10.5 | 8 | 11 | 04 | f | CARBIDE |
| 6H | ITM6014NG | 88 | 15 | 43 | 45 | 10.5 | 8 | 11 | 03 | f | ||
| M14X1.25 | 6H | ITM6014NN | 88 | 12 | 43 | 45 | 10.5 | 8 | 11 | 04 | f | |
| M14X1 | 6H | ITM6014MG | 88 | 12 | 43 | 45 | 10.5 | 8 | 11 | 03 | f | |
| 6H | ITM6014MN | 88 | 6 | 43 | 45 | 10.5 | 8 | 11 | 04 | f | LONG | |
| M15X15 | 6H | ITM6015OG | 95 | 19 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | |
| . | 6H | ITM6015ON | 95 | 10 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | |
| M15X1 | 6H | ITM6015MG | 95 | 12 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | HAND |
| 6H | ITM6015MN | 95 | 10 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | TAPS | |
| 6H | ITM6016QG | 95 | 20 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | ||
| M16X2 | 6H | ITM6016QN | 95 | 12 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | |
| 6H | ITM6016OG | 95 | 20 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | EG (STI) | |
| M16X1.5 | 6H | ITM6016ON | 95 | 12 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | |
| M16X1 | 6H | ITM6016MG | 95 | 12 | 47 | 48 | 12.5 | 10 | 13 | 03 | f | |
| 6H | ITM6016MN | 95 | 8 | 47 | 48 | 12.5 | 10 | 13 | 04 | f | SPECIAL | |
| M17X15 | 6H | ITM6017OG | 100 | 19 | 49 | 51 | 14 | 11 | 14 | 03 | f | THREADS, GAUGES |
| . | 6H | ITM6017ON | 100 | 10 | 49 | 51 | 14 | 11 | 14 | 04 | f | YMW |
| 6H | ITM6017MG | 100 | 12 | 49 | 51 | 14 | 11 | 14 | 03 | f | ||
| M17X1 | 6H | ITM6017MN | 100 | 10 | 49 | 51 | 14 | 11 | 14 | 04 | f | THREAD |
| 6H | ITM6018RG | 100 | 25 | 49 | 51 | 14 | 11 | 14 | 03 | f | MILLS | |
| M18X2.5 | 6H | ITM6018RN | 100 | 16 | 49 | 51 | 14 | 11 | 14 | 04 | f | |
| 6H | ITM6018QG | 100 | 20 | 49 | 51 | 14 | 11 | 14 | 03 | f | ||
| M18X2 | 6H | ITM6018QN | 100 | 12 | 49 | 51 | 14 | 11 | 14 | 04 | f | DIES |
| 6H | ITM6018OG | 100 | 20 | 49 | 51 | 14 | 11 | 14 | 03 | f | ||
| M18X1.5 | 6H | ITM6018ON | 100 | 12 | 49 | 51 | 14 | 11 | 14 | 04 | f | |
| 6H | ITM6018MG | 100 | 12 | 49 | 51 | 14 | 11 | 14 | 03 | f | CENTER | |
| M18X1 | 6H | ITM6018MN | 100 | 8 | 49 | 51 | 14 | 11 | 14 | 04 | f | DRILLS |
