| EG(STI) M | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock |
| JIS | |||||||||||||||
| STI M3X0.5 | 1b | 3.15 | 3.18 | PW3.0G1LEB | 5P | 52 | 7.5 | 17 | 29 | 5 | 4 | 7 | 3 | 001 | f |
| STI M4X0.7 | 1b | 4.2 | 4.27 | PW4.0I1LEB | 5P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 3 | 001 | f |
| STI M5X0.8 | 1b | 5.2 | 5.29 | PW5.0K1LEB | 5P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 3 | 001 | f |
| STI M6X1 | 1b | 6.3 | 6.38 | PW6.0M1LEB | 5P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3 | 002 | f |
| STI M8X1.25 | 1b | 8.4 | 8.47 | PW8.0N1LEB | 5P | 75 | 23 | - | 38 | 7 | 5.5 | 8 | 3 | 002 | f |
| STI M10X1.5 | 1b | 10.5 | 10.56 | PW010O1LEB | 5P | 82 | 26 | - | 42 | 8.5 | 6.5 | 9 | 3 | 002 | f |
| STI M12X1.75 | 1b | 12.6 | 12.66 | PW012P1LEB | 5P | 95 | 26 | - | 48 | 12.5 | 10 | 13 | 3 | 002 | f |
