| Intro | M | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock |
| JIS | ||||||||||||||||
| P4 | 26.5 | 26.63 | TNMS030T520L | 5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | ||
| SP | M30X35 | P4 | 26.5 | 26.63 | TNMS030T120L | 1.5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f |
| . | P4 | 26.5 | 26.63 | TNMS030T525L | 5P | 250 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | |
| P4 | 26.5 | 26.63 | TNMS030T125L | 1.5P | 250 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | ||
| SL | MF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock |
| JIS | ||||||||||||||||
| M10X125 | P2 | 8.8 | 8.85 | TNMQ010N515L | 5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | |
| PO | . | P2 | 8.8 | 8.85 | TNMQ010N115L | 1.5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f |
| P2 | 10.5 | 10.6 | TNMQ012O515L | 5P | 150 | 26 | - | 50 | 8.5 | 6.5 | 9 | 4 | 013 | f | ||
| M12X1.5 | P2 | 10.5 | 10.6 | TNMQ012O115L | 1.5P | 150 | 26 | - | 50 | 8.5 | 6.5 | 9 | 4 | 013 | f | |
| M12X125 | P2 | 10.8 | 10.85 | TNMQ012N515L | 5P | 150 | 26 | - | 50 | 8.5 | 6.5 | 9 | 4 | 013 | f | |
| ST | . | P2 | 10.8 | 10.85 | TNMQ012N115L | 1.5P | 150 | 26 | - | 50 | 8.5 | 6.5 | 9 | 4 | 013 | f |
| M14X15 | P2 | 12.5 | 12.6 | TNMQ014O515L | 5P | 150 | 26 | - | 60 | 10.5 | 8 | 11 | 4 | 013 | f | |
| . | P2 | 12.5 | 12.6 | TNMQ014O115L | 1.5P | 150 | 26 | - | 60 | 10.5 | 8 | 11 | 4 | 013 | f | |
| M16X15 | P2 | 14.5 | 14.6 | TNMQ016O515L | 5P | 150 | 26 | - | 60 | 12.5 | 10 | 13 | 4 | 013 | f | |
| ROLL | . | P2 | 14.5 | 14.6 | TNMQ016O115L | 1.5P | 150 | 26 | - | 60 | 12.5 | 10 | 13 | 4 | 013 | f |
| P2 | 16.5 | 16.6 | TNMQ018O515L | 5P | 150 | 33 | - | 70 | 14 | 11 | 14 | 4 | 013 | f | ||
| M18X1.5 | P2 | 16.5 | 16.6 | TNMQ018O115L | 1.5P | 150 | 33 | - | 70 | 14 | 11 | 14 | 4 | 013 | f | |
| CARBIDE | P3 | 18.5 | 18.6 | TNMR020O515L | 5P | 150 | 33 | - | 70 | 15 | 12 | 15 | 4 | 013 | f | |
| P3 | 18.5 | 18.6 | TNMR020O520L | 5P | 200 | 33 | - | 70 | 15 | 12 | 15 | 4 | 013 | f | ||
| M20X1.5 | P3 | 18.5 | 18.6 | TNMR020O115L | 1.5P | 150 | 33 | - | 70 | 15 | 12 | 15 | 4 | 013 | f | |
| P3 | 18.5 | 18.6 | TNMR020O120L | 1.5P | 200 | 33 | - | 70 | 15 | 12 | 15 | 4 | 013 | f | ||
| LONG | M22X1 | P3 | 20.5 | 20.6 | TNMR022O520L | 5P | 200 | 33 | - | 70 | 17 | 13 | 16 | 4 | 013 | f |
| JIS | .5 | P3 | 20.5 | 20.6 | TNMR022O120L | 1.5P | 200 | 33 | - | 70 | 17 | 13 | 16 | 4 | 013 | f |
| M24X1.5 | P3 | 22.5 | 22.6 | TNMR024O520L | 5P | 200 | 39 | - | 80 | 19 | 15 | 18 | 4 | 013 | f | |
| HAND | P3 | 25.5 | 25.6 | TNMR027O520L | 5P | 200 | 39 | - | 80 | 20 | 15 | 18 | 4 | 013 | f | |
| TAPS | M27X1.5 | P3 | 25.5 | 25.6 | TNMR027O120L | 1.5P | 200 | 39 | - | 80 | 20 | 15 | 18 | 4 | 013 | f |
| M30X3 | P3 | 27 | 27.13 | TNMR030S520L | 5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | |
| M30X2 | P3 | 28 | 28.12 | TNMR030Q520L | 5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | |
| EG (STI) | P3 | 28.5 | 28.6 | TNMR030O520L | 5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | |
| M30X1.5 | P3 | 28.5 | 28.6 | TNMR030O120L | 1.5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f |
