| M | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | Intro |
| JIS | P4 | 26.5 | 26.63 | TNMS030T520 | 5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | |
| P4 | 26.5 | 26.63 | TNMS030T525 | 5P | 250 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | SP | |
| P4 | 26.5 | 26.63 | TNMS030T530 | 5P | 300 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | ||
| M30X3.5 | P4 | 26.5 | 26.63 | TNMS030T120 | 1.5P | 200 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | |
| P4 | 26.5 | 26.63 | TNMS030T125 | 1.5P | 250 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | ||
| P4 | 26.5 | 26.63 | TNMS030T130 | 1.5P | 300 | 46 | - | 80 | 23 | 17 | 20 | 4 | 013 | f | SL | |
| M33X3 | P4 | 29.5 | 29.63 | L25033T5-S | 5P | 250 | 51 | - | 80 | 25 | 19 | 22 | 4 | 013 | f | |
| .5 | P4 | 29.5 | 29.63 | L25033T1-S | 1.5P | 250 | 51 | - | 80 | 25 | 19 | 22 | 4 | 013 | f | |
| P4 | 32 | 32.12 | L25036U5-S | 5P | 250 | 57 | - | 100 | 28 | 21 | 24 | 4 | 013 | f | PO | |
| M36X4 | P4 | 32 | 32.12 | L30036U5-S | 5P | 300 | 57 | - | 100 | 28 | 21 | 24 | 4 | 013 | f | |
| P4 | 32 | 32.12 | L25036U1-S | 1.5P | 250 | 57 | - | 100 | 28 | 21 | 24 | 4 | 013 | f | ||
| P4 | 32 | 32.12 | L30036U1-S | 1.5P | 300 | 57 | - | 100 | 28 | 21 | 24 | 4 | 013 | f | ||
| P4 | 35 | 35.12 | L30039U5-S | 5P | 300 | 60 | - | 100 | 30 | 23 | 26 | 4 | 013 | f | ST | |
| M39X4 | P4 | 35 | 35.12 | L30039U1-S | 1.5P | 300 | 60 | - | 100 | 30 | 23 | 26 | 4 | 013 | f | |
| P4 | 37.5 | 37.63 | L25042V5-S | 5P | 250 | 60 | - | 100 | 32 | 26 | 30 | 4 | 013 | f | ||
| P4 | 37.5 | 37.63 | L30042V5-S | 5P | 300 | 60 | - | 100 | 32 | 26 | 30 | 4 | 013 | f | ||
| M42X4.5 | P4 | 37.5 | 37.63 | L25042V1-S | 1.5P | 250 | 60 | - | 100 | 32 | 26 | 30 | 4 | 013 | f | ROLL |
| P4 | 37.5 | 37.63 | L30042V1-S | 1.5P | 300 | 60 | - | 100 | 32 | 26 | 30 | 4 | 013 | f | ||
| P4 | 40.5 | 40.63 | L30045V5-S | 5P | 300 | 67 | - | 100 | 35 | 26 | 30 | 4 | 013 | f | ||
| M45X4.5 | P4 | 40.5 | 40.63 | L30045V1-S | 1.5P | 300 | 67 | - | 100 | 35 | 26 | 30 | 4 | 013 | f | CARBIDE |
| P4 | 43 | 43.12 | L30048W5-S | 5P | 300 | 67 | - | 100 | 38 | 29 | 32 | 4 | 013 | f | ||
| M48X5 | P4 | 43 | 43.12 | L30048W1-S | 1.5P | 300 | 67 | - | 100 | 38 | 29 | 32 | 4 | 013 | f | |
| MF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | LONG |
| JIS | ||||||||||||||||
| JIS | ||||||||||||||||
| P2 | 7 | 7.09 | TNMQ8.0M510 | 5P | 100 | 19 | - | 50 | 6.2 | 5 | 8 | 4 | 013 | f | ||
| P2 | 7 | 7.09 | TNMQ8.0M512 | 5P | 120 | 19 | - | 50 | 6.2 | 5 | 8 | 4 | 013 | f | HAND | |
| M8X1 | P2 | 7 | 7.09 | TNMQ8.0M515 | 5P | 150 | 19 | - | 50 | 6.2 | 5 | 8 | 4 | 013 | f | TAPS |
| P2 | 7 | 7.09 | TNMQ8.0M110 | 1.5P | 100 | 19 | - | 50 | 6.2 | 5 | 8 | 4 | 013 | f | ||
| P2 | 7 | 7.09 | TNMQ8.0M112 | 1.5P | 120 | 19 | - | 50 | 6.2 | 5 | 8 | 4 | 013 | f | ||
| P2 | 7 | 7.09 | TNMQ8.0M115 | 1.5P | 150 | 19 | - | 50 | 6.2 | 5 | 8 | 4 | 013 | f | EG (STI) | |
| P2 | 8.8 | 8.85 | TNMQ010N510 | 5P | 100 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P2 | 8.8 | 8.85 | TNMQ010N512 | 5P | 120 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P2 | 8.8 | 8.85 | TNMQ010N515 | 5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | SPECIAL | |
| P2 | 8.8 | 8.85 | TNMQ010N520 | 5P | 200 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | THREADS, GAUGES | |
| P2 | 8.8 | 8.85 | TNMQ010N110 | 1.5P | 100 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P2 | 8.8 | 8.85 | TNMQ010N112 | 1.5P | 120 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P2 | 8.8 | 8.85 | TNMQ010N115 | 1.5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | THREAD | |
| MILLS | ||||||||||||||||
| P2 | 8.8 | 8.85 | TNMQ010N120 | 1.5P | 200 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| M10X1.25 | P3(P2+20) | 8.8 | 8.85 | TNMR010N510 | 5P | 100 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | |
| P3(P2+20) | 8.8 | 8.85 | TNMR010N110 | 1.5P | 100 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P4(P2+40) | 8.8 | 8.85 | TNMS010N510 | 5P | 100 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | DIES | |
| P4(P2+40) | 8.8 | 8.85 | TNMS010N515 | 5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P4(P2+40) | 8.8 | 8.85 | TNMS010N110 | 1.5P | 100 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | ||
| P4(P2+40) | 8.8 | 8.85 | TNMS010N115 | 1.5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | CENTER | |
| P3(P2+20) | 8.8 | 8.85 | TNMR010N515 | 5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f | DRILLS | |
| P3(P2+20) | 8.8 | 8.85 | TNMR010N115 | 1.5P | 150 | 23 | - | 50 | 7 | 5.5 | 8 | 4 | 013 | f |
